CONNECTING CONVEYOR

Document:

Updating..

This unit is used to connect previous/next machine effectively in the production line.

Features					Options
SMEMA Interface					Touch screen
Stable design with double plate structure					Tower Light
PLC control					Auto width adjustment
					Speed Controller
					Cooling Fan - Cooling time adjustable
					ESD safety cover
					Added segment for holding lots of PCBs
					Chain Belt for heat-resistance

Model	Max. PCB		Min. PCB		Dimension			Power	Weight
KCC-900S	330	250	50	50	900	500	920	100 VA	70
KCC-900Y	440	330	50	50	900	580	920	100 VA	80
KCC-900L	530	380	50	50	900	630	920	100 VA	90
KCC-900X	530	460	50	50	900	700	920	100 VA	100
KCC-900XX	610	460	50	50	900	760	920	100 VA	110
