Yamaha YS24 part
Base
KKE-M1118-00 PLATE 18 1
$NK-3N NYLON CLIP 12
97602-05310 SCREW, PAN HEAD W/W 19
90990-11J003 SCREW, PAN HEAD W/W 14
KKE-M1122-00 PLATE 22 1
KKE-M1115-00 PLATE 15 1
$NK-4N NYLON CLIP 6
KKE-M1128-00 PLATE, CONV. 1
KKE-M1338-00 BRKT. MAIN SWITCH 1
KKE-M1336-00 BRKT. REAR LEFT 1
KKE-M1337-00 BRKT. REAR RIGHT 1
KKE-M111M-00 PLATE, CLAMP 1
KGS-M1371-00 BRACKET, FIX 8
KKE-M1163-00 BRACKET 2, FAN 1
KHY-M1162-01 BRACKET,FAN 1 OK MFX0104-2009/11/26
KKE-M1162-00 DUCT 1
KKE-M11H5-00 PLATE 1
KKE-M11H6-01 PLATE, FAN 1 1 FAN type NG MFX0027-2009/12/8
KKE-M11H6-00 PLATE, FAN 1 2 FAN type
KKE-M1151-01 PLATE, SIDE 1 1
KKE-M1152-01 PLATE, SIDE 2 1
KKE-M11F1-00 STAY C/R, R 1
KKE-M11F2-00 STAY C/R, L 1
KKE-M11F4-00 FILTER 2
KKE-M11F3-00 PLATE 2
KKE-M11F5-00 TAPE 2
KKE-M11H1-00 PLATE, FAN 1
KKE-M11H3-00 DUCT, FAN 1
KKE-M11H4-00 DUCT, FAN 2 1
KKE-M1131-00 COVER, PU AXIS 1
KKE-M1132-00 COVER, PU AXIS 2
92012-05010 BOLT, BUTTON HEAD 6
90172-00J050 WASHER, EXTL. TOOTHED 6
90990-12J004 SCREW, BIN. HEAD W/W 10
90990-23J004 GROMMET 2
91312-04006 BOLT HEX. SOCKET HEAD 8
91312-04020 BOLT HEX. SOCKET HEAD 4
91312-05006 BOLT HEX. SOCKET HEAD 1
91312-05008 BOLT HEX. SOCKET HEAD 7
91312-05010 BOLT HEX. SOCKET HEAD 8
91312-05012 BOLT HEX. SOCKET HEAD 8
92902-04200 WASHER, PLAIN 4
92902-05200 WASHER, PLAIN 14
97602-04308 SCREW, PAN HEAD W/W 2
98902-05010 SCREW, BINDING HEAD 16
91312-03006 BOLT HEX. SOCKET HEAD 4
KKE-M1114-01 PLATE 14 (I/O) 1
KKE-M1126-00 PLATE 26 1
KKE-M111L-00 BRKT. 1 POWER SUPPLY 1
KKE-M111K-00 BRKT. 2 POWER SUPPLY 1
KKE-M1151-11 PLATE,SIDE 1 1 UPS
KKE-M1153-10 PLATE,SIDE 3 1 UPS
KJJ-M1155-00 BRACKET,UPS 1 UPS
KHW-M1157-00 BRACKET 2,UPS 1 UPS
KHW-M1158-00 PLATE,UPS 1 UPS
KHW-M1160-00 COVER,HARNESS 1 UPS
KHW-M1161-00 BRACKET 3,UPS 1 UPS
KV7-M1515-00 PLATE,RUBBER 1 UPS
90990-12J004 SCREW BIN.HEAD W/W 18 UPS
92902-04200 WASHER PLAIN 5 UPS
91312-04006 BOLT HEX.SOCKET HEAD 8 UPS
Sub Assy
KGA-M1180-00 LEVELING BOLT ASSY 4
KKE-M1111-00 PLATE 11 1
KHY-M8504-00 REGULATOR 2
$SL12-03 JOINT 2
$SLY10-03 JOINT 2
$TL4-02 JOINT 2
90990-12J004 SCREW BIN. HEAD W/W 5
KG7-M8501-00 AIR FILTER 1
KV8-M8502-00 MIST FILTER (MF400-A) 1
KV8-M8503-00 MODULE ADAPTER (8-4D) 1
KKE-M1125-00 PLATE 25 1
90990-42J006 JOINT 1
90990-42J008 JOINT 1
$SL12-03 JOINT 3
KH5-M8501-00 EXHAUST VALVE 1
$KM-22 MUFFLER 1
KHM-M1397-00 BRACKET, FDD 3 1
90K41-000540 LABEL, ALERT 1
91312-06012 BOLT HEX. SOCKET HEAD 2
92902-06200 WASHER PLAIN 2
91312-05010 BOLT HEX. SOCKET HEAD 2
91312-04008 BOLT HEX. SOCKET HEAD 4
98902-04006 SCREW BINDING HEAD 4
KM7-M8584-00 MANIFOLD 1
$UY8 JOINT 1
$TL8-01 JOINT 1
$KM-11 MUFFLER 4
91317-03025 BOLT HEX. SOCKET HEAD 2
KKE-M8582-00 VALVE 1
$SL8-01 JOINT 2
KKE-M1123-00 PLATE 23 1
KKE-M111G-00 COVER, TERMINAL 1
91312-03030 BOLT HEX. SOCKET HEAD 4
91312-06010 BOLT HEX. SOCKET HEAD 4
KKE-M1339-00 BRACKET FL 1
99563-03J450 SPACER BOLT 4
91312-03006 BOLT HEX. SOCKET HEAD 4
$KM-31 MUFFLER 2
90172-00J050 WASHER, EXTL. TOOTHED 6
91312-05010 BOLT HEX. SOCKET HEAD 8
92902-05200 WASHER, PLAIN 14
KV7-M8583-00 OPTION MANIFOLD ASSY 1
KHW-M8582-40 VALVE 1 (Spare)
KHY-M8596-00 PRESSURE GAUGE 2
KHW-M8597-00 BRACKET, GAUGE 2
$SL4-M5 JOINT 2
KG7-M8501-40 FILTER ELEMENT 1
KV8-M8502-40 MIST FILTER ELEMENT 1
KHW-M8582-40 VALVE 1 (Spare)
KHY-M11B0-00 AIR TAG 1
Top Cover
KKE-M1301-00 COVER 1 2
KKE-M130B-00 COVER, 1-2 2
KKE-M1302-00 COVER 2 2
KKE-M1306-00 COVER 6 1
KKE-M130H-00 COVER 6-1 2
KKE-M13A5-01 COVER A5 1 Front S.T.D (above illust)
KKE-M13A5-10 COVER A5 1 Rear S.T.D
KKE-M13A6-02 COVER A6 1 Front S.T.D (above illust)
KKE-M13A6-10 COVER A6 1 Rear S.T.D
KKE-M13A7-01 COVER A7 2
KKE-M13A8-00 COVER A8 2
KGA-M1318-00 COVER 18 2
KKE-M1331-01 BRKT. 31, SIDE COVER 2
90990-23J026 GROMMET 8
90990-23J027 GROMMET 8
KKE-M1334-01 BRKT. 1, GATE COVER 2
KKE-M130F-01 BRKT., FAN 1 NG MFX0027-2009/12/8
KKE-M130F-00 BRKT., FAN 1
KKE-M130J-01 COVER, FAN 1 NG MFX0027-2009/12/8
KKE-M130J-00 COVER, FAN 1
KKE-M13M1-00 PLATE, M1 2
KKE-M13M2-00 PLATE, M2 2
KKE-M130C-00 PLATE, KB 2
K46-M1374-11 HINGE 2 4
KM0-M1332-01 BRACKET, MAGNET 4
KV5-M1130-00 CATCH MG. 4
90990-23J008 GROMMET 2
90K41-000490 LABEL, ALERT 2
90K41-000380 LABEL, ALERT 4
KGA-M1392-00 PLUG (φ30) 6
KH1-M13A9-00 BUSH 2
K11-M1591-00 GROMMET 2
KV7-M1391-10 PLUG 8
90990-01J050 BOLT HEX. SOCKET 2
90990-12J001 SCREW, BIN. HEAD W/W 80
90990-12J003 SCREW, BIN. HEAD W/W 36
90990-46J001 BOLT, THIN HEAD 4
90990-46J006 BOLT, THIN HEAD 12
91312-04006 BOLT HEX. SOCKET HEAD 12
91312-04030 BOLT HEX. SOCKET HEAD 16
91312-05008 BOLT HEX. SOCKET HEAD 12
98902-03005 SCREW, BINDING HEAD 8
98902-04010 SCREW, BINDING HEAD 24
98902-04006 SCREW, BINDING HEAD 8
KKE-M1335-01 BRKT. 2, GATE COVER 2
KKE-M1332-00 BRKT. 32, CON. COVER 2
KKE-M135A-00 PLATE C, JOINT 2
KKE-M1356-00 PLATE 1, JOINT 2
KKE-M1357-00 PLATE 2, JOINT 2
91312-05010 BOLT HEX. SOCKET HEAD 24
91312-05008 BOLT HEX. SOCKET HEAD 6
KKE-M1329-00 COVER 29 2
98902-03008 SCREW, BINDING HEAD 6
Acril Door
KKE-M1309-00 COVER 9-1 (STD) 1
KKE-M130A-00 COVER 9-2 1
KKE-M130G-00 COVER 9-3 1
KKE-M1340-00 BRKT. 1, COVER 9 1
KKE-M1341-00 BRKT. 2, COVER 9 1
KHY-M1343-01 BRKT. 4, CVOER 9 1
KV2-M1351-00 PLATE 2, NUT 4
KH2-M1324-01 GRIP 1
KM0-M1331-01 BRACKET, GAS DAMPER 2
KGS-M1348-00 GAS, SPRING 2
90990-31J006 BOLT, SHOULDER 4
KL0-M1373-01 BRACKET 1, SCHMEASAL 1
KL0-M1374-00 PLATE 1, SCHMEASAL 1
KJJ-M1348-00 STOPPER 65 2
KGS-M1360-00 BOLT 4
90990-46J001 BOLT, THIN HEAD 12
90990-46J003 BOLT, THIN HEAD 10
91312-04006 BOLT HEX. SOCKET HEAD 4
91312-04008 BOLT HEX. SOCKET HEAD 2
91312-05010 BOLT HEX. SOCKET HEAD 2
91312-06010 BOLT HEX. SOCKET HEAD 4
92902-04200 WASHER, PLAIN 2
95302-06600 NUT, HEXAGON 2
KHW-M1381-00 BODY, STAND 1
KHY-M1382-00 BRACKET 1 1
KHY-M1386-00 BRACKET 2 1
KHW-M1383-00 BRACKET 2 2
KKE-M1384-00 BRACKET, LCD 1
KHW-M1385-00 SPACER 8
KHW-M1386-00 BUSH 4
KHY-M1385-10 STAY, LCD UNIT 1
KKE-M138A-00 DAMPER 4
90990-28J141 WASHER, PLAIN 8
90990-41J132 COLLAR 4
90990-37J001 WASHER, BELLEVILLE 8
90990-06J001 BOLT, BUTTON HEAD 1
91312-04006 BOLT HEX. SOCKET HEAD 1
91312-04008 BOLT HEX. SOCKET HEAD 4
91312-05010 BOLT HEX. SOCKET HEAD 4
91312-05014 BOLT HEX. SOCKET HEAD 4
91312-06008 BOLT HEX. SOCKET HEAD 1
91312-06020 BOLT HEX. SOCKET HEAD 4
92902-04200 WASHER, PLAIN 4
92902-05200 WASHER, PLAIN 8
92902-06600 WASHER, PLAIN 2
90172-00J040 WASHER, EXTL. TOOTHED 4
90172-00J050 WASHER, EXTL. TOOTHED 8
95602-06100 NUT, U 4
$NK-2N NYLON CLIP 5
90990-11J001 SCREW, PAN HEAD W/W 5
98902-04016 SCREW, BINDING HEAD 4
90K41-001040 LABEL, ALERT 2
90K41-000420 LABEL, ALERT 2
KKE-M13D6-00 SEAL 1 (YS24) 1
90K41-000360 LABEL, ALERT 2
KHY-M13D8-00 STICKER 1
KW7-M13D7-01 SEAL 2 (YAMAHA) 1
KHY-M13D8-10 STICKER 1
KKE-M1309-A0 COVER 9 ASSY. 2
KHY-M1391-00 PLATE, PROTECTOR 6
90990-12J003 SCREW BIN. HEAD W/W 12
Base / Conveyor / CE Cover
KHU-M1117-00 PULL 2
KKE-M1310-00 COVER 10 2
KKE-M132A-00 COVER 10-1 2
KKE-M1311-00 COVER 11 1
KHY-M1312-00 COVER 12 2
KKE-M1313-00 COVER 13 1
KKE-M132B-00 COVER 13-1 1
KHY-M131A-00 BRKT. 1, COVER 12 2
KHY-M131B-00 BRKT. 2, COVER 12 2
KKE-M130K-00 DAMPER 5
KHY-M1164-00 COVER, FAN 1
90990-12J004 SCREW, BIN. HEAD W/W 24
KH1-M1396-00 WASHER 16
KKE-M132D-00 COVER 11-1 1
KHY-M130E-00 DOOR, COVER 11 1
KGJ-M1350-00 SPACER, MINI LATCH 1
KGJ-M1351-01 PLATE, MINI LATCH 1
KW3-M1349-00 MINI LATCH 1
90990-12J006 SCREW, BIN. HEAD W/W 10
KHY-M13F1-01 CE COVER F1 2
KHY-M13F2-01 CE COVER F2 2
KJJ-M13A3-10 COVER CE C BRKT 2
KJJ-M13A3-01 COVER CE C MAIN 2
KJJ-M13AB-A0 HOLDER ASSY 4
90990-12J001 SCREW, BIN. HEAD W/W 48
90990-12J003 SCREW, BIN. HEAD W/W 8
91312-06010 BOLT HEX. SOCKET HEAD 4
90172-00J060 WASHER, EXTL. TOOTHED 4
92902-06200 WASHER, PLAIN 4
98907-04008 SCREW, BINDING HEAD 8
KHY-M13F3-00 CE COVER F3 2 FES
KHY-M13F4-00 CE COVER F4 2 FES
KHY-M13F5-00 CE COVER F5 2 FES
90990-12J001 SCREW BIN. HEAD W/W 16 FES
KKE-M1372-00 COVER 72, CON. 2
98902-04008 SCREW BINDING HEAD 10
90172-00J040 WASHER, EXTL. TOOTHED 10
KKE-M1376-00 COVER, CON. S 1
KKE-M1377-00 COVER, CON. UPPER S 1
KKE-M1378-00 COVER, CON. L 1
KKE-M1379-00 COVER, CON. UPPER L 1
KKE-M137A-00 PLATE, CON. COVER 2
90990-12J006 SCREW BIND HEAD W/W 12
90990-12J001 SCREW BIND HEAD W/W 8 STD. 1460, OPT. 1460
90990-12J001 SCREW BIND HEAD W/W 12 OPT. 1250
KKE-M1371-00 COVER 71, CON. 2 OPT. 1250
KKE-M1371-00 COVER 71, CON. 4 OPT. 1460
KKE-M1373-00 COVER 73, CON. 4 OPT. 1250
Feeder Holder Fix 60
KHY-M3401-01 PLATE, FEEDER 60 1
KHY-M3405-00 STAND 1 1
KHY-M3406-00 STAND 2 1
KHY-M340C-01 PLATE, FRONT 2
KHY-M371R-00 RAIL GUIDE 12P 5
KHY-M340F-00 BRACKET, BOARD 2
KHY-M4476-16 FDR.CTRL. BOARD ASSY 2 without pnp Changer
KHY-M37E1-00 LIGHT GUIDE 4
KHY-M37E1-10 LIGHT GUIDE, L 2
KHY-M37E1-20 LIGHT GUIDE, R 2
KHY-M340G-00 SHAFT GUIDE 2
KHY-M340H-01 PLATE, INDICATOR 1
KHY-M349J-40 LABEL, INDICATOR 1
KHY-M379K-01 LABEL, LED POSI. 2
KHY-M340J-00 PLATE, CONNECTOR 1
KHY-M66TE-00 HNS, F.CTRL- FDR. 60
KHY-M372M-00 SCREW, STAD 120
KHY-M340K-01 BRACKET, MANIFOLD 1
KHY-M372R-00 GUIDE, FEEDER UNDER 5
KHY-M372P-00 SUPPORT, LEVER 60
KHY-M372S-01 SPRING, SUPPORT 60
KHY-M340N-01 COVER, BOARD 2
KHY-M3411-00 MANIFOLD 1
K40-M8598-00 PLUG 1 1
$TSH8-01 JOINT 1
$TSS4-01 JOINT 6
KHY-M34J1-00 BLOCK, FEEDER POSI. 2
KHY-M3430-10 LABEL, FEEDER 60-12P 1 1-60
KHY-M3430-20 LABEL, FEEDER 60-12P 1 101-160
99480-06020 PIN, PARALLEL 4
99480-06012 PIN, PARALLEL 4
99480-04012 PIN, PARALLEL 2
91312-08020 BOLT HEX. SOCKET HEAD 6 M8X20
91312-06020 BOLT HEX. SOCKET HEAD 4 M6X20
91312-06018 BOLT HEX. SOCKET HEAD 4 M6X18
91312-06016 BOLT HEX. SOCKET HEAD 4 M6X16
91312-06012 BOLT HEX. SOCKET HEAD 18 M6X12
91312-04008 BOLT HEX. SOCKET HEAD 12 M4X8
91312-03018 BOLT HEX. SOCKET HEAD 32 M3X18
91312-03016 BOLT HEX. SOCKET HEAD 12 M3X16
91312-03010 BOLT HEX. SOCKET HEAD 4 M3X10
98702-03006 SCREW FLAT HEAD 90
98902-03006 SCREW BINDING HEAD 16
92902-06200 WASHER PLAIN 4
92902-08600 WASHER PLAIN 6
$NK-3N NYLON CLIP 10
90990-11J003 SCREW, PAN HEAD W/W 10
KHY-M6187-00 FAN MOTOR ASSY 4
KHY-M379L-00 LABEL, LED 2
KV8-M3758-00 SEAL (DUMP) 2
Feeder Holder Fix 24.
KJH-M3401-01 PLATE, FEEDER 12-24 1
KKJ-M3405-01 STAND 1 1
KKJ-M3406-01 STAND 2 1
KJH-M340F-02 BRACKET, BOARD 1
KJH-M340H-02 PLATE, INDICATOR 1
KJH-M340J-00 PLATE, CONNECTOR 1
KJH-M340K-01 BRACKET 1, MANIFOLD 1 L, R
KJH-M340K-10 BRACKET 2, MANIFOLD 1 R-With Tape Cutter
KJH-M340N-02 COVER, BOARD 1
KJH-M3410-10 MANIFOLD ASSY 1 R
KKJ-M3410-00 MANIFOLD ASSY 1 L
KHY-M34J1-00 BLOCK, FEEDER POSI. 2
KHY-M371A-01 PLATE, FRONT 1
KHY-M371B-00 SHAFT GUIDE 1
KHY-M371R-00 RAIL GUIDE 12P 2
KHY-M372M-00 SCREW, STAD 48
KHY-M372P-00 SUPPORT, LEVER 24
KHY-M372R-00 GUIDE, FEEDER UNDER 2
KHY-M372S-01 SPRING, SUPPORT 24
KHY-M349J-40 LABEL, INDICATOR 1
KHY-M379K-01 LABEL, LED POSI. 1
KHY-M37E1-00 LIGHT GUIDE 3
KHY-M4476-06 FDR. CTRL. BOARD ASSY 1
KHY-M6187-00 FAN MOTOR ASSY 2
KHY-M66TE-00 HNS, F. CTRL – FDR. 24
KV8-M3758-00 SEAL DUMP 1
KJJ-M3T0X-00 STAY L 1
KJJ-M3T0X-10 STAY R 1
99480-06012 PIN, PARALLEL 8
99480-06020 PIN, PARALLEL 4
91312-03006 BOLT HEX. SOCKET HEAD 4
91312-03010 BOLT HEX. SOCKET HEAD 2
91312-03016 BOLT HEX. SOCKET HEAD 6
91312-03018 BOLT HEX. SOCKET HEAD 14
91312-04006 BOLT HEX. SOCKET HEAD 4
91312-04008 BOLT HEX. SOCKET HEAD 10
91312-06012 BOLT HEX. SOCKET HEAD 9
91312-06016 BOLT HEX. SOCKET HEAD 4
91312-06018 BOLT HEX. SOCKET HEAD 8
91312-06020 BOLT HEX. SOCKET HEAD 4
91312-08030 BOLT HEX. SOCKET HEAD 6
98702-03006 SCREW, FLAT HEAD 36
98902-03006 SCREW, BINDING HEAD 6
92902-06200 WASHER, PLAIN 4
92902-04600 WASHER, PLAIN 4
92902-08600 WASHER, PLAIN 6
KHY-M379L-00 LABEL, LED 1
KHY-M3430-00 LABEL, FEEDER 24-12P 1
91312-08060 BOLT HEX. SOCKET HEAD 2
99480-04012 PIN, PARALLEL 1
$TSS4-01 JOINT 3
$TSH8-01 JOINT 1
Clamp Unit
KHY-M3761-00 BASE, R 4
KHY-M3762-00 BASE, L 4
KHY-M3763-00 UPPER PLATE, R 4
KHY-M3764-00 UPPER PLATE, L 4
KHY-M3765-00 SLIDE PLATE 8
KHY-M3766-00 CLAMP PLATE, R 4
KHY-M3767-00 CLAMP PLATE, L 4
KHY-M3768-00 GUIDE PLATE, R 4
KHY-M3769-00 GUIDE PLATE, L 4
KHY-M3783-00 CYLINDER 8
KHY-M3796-00 SIDE COVER, 1-R 4
KHY-M3797-00 SIDE COVER, 1-L 4
KHY-M379A-00 UNDER COVER 4
KHY-M379B-00 BRKT., UNDER COVER 4
KHY-M379F-00 SIDE COVER, 2-R 4
KHY-M379F-10 SIDE COVER, 2-L 4
KHY-M379H-00 GUIDE, HNS 4
KHY-M37B2-00 TAPE PROTECTOR R 4
KHY-M37B3-00 TAPE PROTECTOR L 4
KHY-M37C2-00 COVER 8
KHY-M3AA6-00 SAFETY PAD 8
KU5-M3A92-00 PUSH PIN 8
KHY-M3AA3-00 GUIDE BLOCK 8
KV8-M3759-00 BLIND BUSH 8
KV8-M3784-00 CYLINDER JOINT, A 8
KV8-M3785-01 CYLINDER JOINT, B 8
KV8-M3789-00 GUIDE 8
KV8-M3791-00 BLOCK 8
KV8-M3794-00 SPG. 8
KV8-M37A7-00 PAD 8
KV8-M37A9-00 AIR PILOTED VALVE 4
90990-42j033 JOINT 4
KV8-M37S2-00 AIR SOCKET, 2 ASSY 8
KHY-M66R2-00 HNS, CLAMP MKY F1, R1 2 F. L.
KHY-M66R3-00 HNS, CLAMP PWR F1, R1 2 F. R.
KHY-M66R2-10 HNS, CLAMP MKY F2, R2 2 R. R.
KHY-M66R3-10 HNS, CLAMP PWR F2, R2 2 R. L.
KHY-M3T0R-10 STAY R 1
KHY-M3T0R-00 STAY L 1
$TL4-01M JOINT 4
$TL4-02 JOINT 8
$TSH4-M5M JOINT 8
91312-03006 BOLT HEX. SOCKET HEAD 12 M3X6
91312-04008 BOLT HEX. SOCKET HEAD 14 M4X8
91312-04010 BOLT HEX. SOCKET HEAD 4 M4X10
91312-04012 BOLT HEX. SOCKET HEAD 16 M4X12
91312-04014 BOLT HEX. SOCKET HEAD 8 M4X14
91312-04016 BOLT HEX. SOCKET HEAD 8 M4X16
91312-04030 BOLT HEX. SOCKET HEAD 2 M4X30
91312-05010 BOLT HEX. SOCKET HEAD 2 M5X10
91312-05020 BOLT HEX. SOCKET HEAD 12 M5X20
91312-05025 BOLT HEX. SOCKET HEAD 4 M5X25
91312-06065 BOLT HEX. SOCKET HEAD 8 M6X65
91312-08025 BOLT HEX. SOCKET HEAD 8 M8X25
92907-08200 WASHER PLAIN 8
92A08-03303 SET SCREW M3X3 2
98902-03006 SCREW BINDING HEAD 24
98702-03006 SCREW FLAT HEAD 10
99480-06014 PIN, PARALLEL 8
KHY-M3798-00 C/U COVER R 4
KHY-M3799-00 C/U COVER L 4
98902-03010 SCREW BINDING HEAD 4
98902-04006 SCREW BINDING HEAD 4
90112-2A008 BOLT HEX. SOCKET HEAD 4
92902-04600 WASHER PLAIN 2
KKE-M652G-00 SENSOR F1 R1 FWD ASSY 1
Reel Holder 60
KHY-M3S00-00 REEL HOLDER 60 ASSY 1
KHY-M3S07-01 TRIM 2
KHY-M3S08-00 UNDER COVER 1
KHY-M3S09-00 SHAFT, ROLLER 4
KHY-M3R10-02 REEL PUT 30
KHY-M3R14-00 COLLAR 4
KHW-M1385-00 SPACER 32
KHY-M3R15-00 ROLLER 98
KHY-M3S15-00 ROLLER 2 2
KHY-M3R16-00 PARTITION 15
KHY-M3R22-00 GUIDE, PARTITION 7
KHY-M3S22-00 GUIDE 2, PARTITION 1
KHY-M3R23-00 COLLAR, PARTITION 29
KHY-M3S23-00 COLLAR 2, PARTITION 1
KHY-M3S20-S1 RH FRAME SUB ASSY 1
KHY-M373C-10 CHAIN ASSY 1
KHY-M374C-00 CASTER 2
91312-06012 BOLT HEX. SOCKET HEAD 8 M6X12
91312-06008 BOLT HEX. SOCKET HEAD 16 M6X10
91312-03014 BOLT HEX. SOCKET HEAD 16 M3X14
91312-03005 BOLT HEX. SOCKET HEAD 12 M3X5
92902-03200 WASHER PLAIN 8
91312-04008 BOLT HEX. SOCKET HEAD 17
90172-00J040 WASHER,EXTL.TOOTHED 1
KHY-M3R01-00 SIDE PLATE, R 1
KHY-M3R02-00 SIDE PLATE, L 1
KHY-M3S06-02 STOPPER PLATE 1
KHY-M3S20-00 RH. FRAME ASSY 1
KM0-M3741-00 CASTER 63 2
KHY-M3S0A-00 STAY,SHAFT 3
92902-04200 WASHER, PLAIN 16
Feeder Floating Detection
KJJ-M3790-00 COVER, HNS 2
KJJ-M3790-10 COVER, HNS 2
KHY-M3901-00 BRACKET SENSOR 2 4 FIX 24
KHY-M3901-00 BRACKET SENSOR 2 8 FES 24, FIX 60
KHY-M3910-00 BRACKET SENSOR 1 4
KGS-M3906-00 BRACKET 6 4 FIX 24
KGS-M3906-00 BRACKET 6 6 FES 24, FIX 60
KHY-M3951-00 PLATE SENSOR 4 FIX 60, FIX 24
KHY-M3951-00 PLATE SENSOR 2 FES 24
KKE-M652F-00 SENSOR, FEE. FLT. ASSY 4
90112-02J004 BOLT HEX. SOCKET HEAD 8
91312-03010 BOLT HEX. SOCKET HEAD 4 FIX 60
91312-03010 BOLT HEX. SOCKET HEAD 8 FES 24, FIX 24
91312-04010 BOLT HEX. SOCKET HEAD 24 FIX 24
91312-04010 BOLT HEX. SOCKET HEAD 10 FES 24, FIX 60
90990-11J003 SCREW, PAN HEAD W/W 2
92902-03200 WASHER, PLAIN 4 FIX 60
92902-03200 WASHER, PLAIN 8 FES 24, FIX 24
92902-04200 WASHER, PLAIN 16 FIX 60, FIX 24
92902-04200 WASHER, PLAIN 8 FES 24
$NK-2N NYLON CLIP 4
KG2-M3903-10 SEAL, LASER 2 FIX 60
KG2-M3903-10 SEAL, LASER 4 FES 24, FIX 24
92902-05200 WASHER, PLAIN 8
91312-05014 BOLT HEX. SOCKET HEAD 8
98902-03006 SCREW, BINDING HEAD 4 FES 24
KHY-M3791-00 COVER, HNS 2 FES 24
KHY-M3792-00 COVER, HNS 2 FES 24
KHY-M3952-00 PLATE SENSOR 2 FIX 60
KHY-M3953-00 BRACKET SENSOR 3 2 FIX 60
90112-02J006 BOLT HEX. SOCKET HEAD 4 FES 24
90112-02J006 BOLT HEX. SOCKET HEAD 2 FIX 60
X-axis-Motor/ Sensor/ Duct/ Cover/ Joint
KKE-M0201-00 XB AXIS SUB ASSY 1
KKE-M2267-00 GUIDE, X AXIS 1
KHY-M220A-00 TAPE, X DUCT 1
KHY-M220B-00 TAPE 2, X DUCT 1
KHY-M220C-00 TAPE 3, X DUCT 1
KHY-M226B-01 COVER BACK, X AXIS 1 B-Table
KKE-M226B-50 COVER BACK, XA AXIS 1 A-Table
KHY-M22C5-00 COVER UNDER, AXIS 1 B-Table
KKE-M22C5-50 COVER UNDER, XA AXIS 1 A-Table
KHY-M227G-00 COVER, B.S. 1
KKE-M652D-10 SENSOR XB ORG ASSY 1 B-Table
KKE-M652D-00 SENSOR XA ORG ASSY 1 A-Table
KKE-M652E-10 SENSOR XB OT ASSY 1 B-Table
KKE-M652E-00 SENSOR XA OT ASSY 1 A-Table
KKE-M2282-00 DOG, ORIGIN B 1 B-Table
KKE-M2282-50 DOG, ORIGIN A 1 A-Table
KKE-M2283-00 DOG, SECOND LIMIT B 2 B-Table
KKE-M2283-50 DOG, SECOND LIMIT A 2 A-Table
KKE-M2284-00 BRACKET, SENSOR B 1
KHY-M221A-A0 COVER DUCT ASSY. 1
KKE-M2269-00 BRACKET 2, TAPE 1
KHY-M2268-00 BRACKET 1, TAPE 1
KGT-M2266-10 PLATE, NUT 1
KV7-M7165-00 SEAL DON’T TOUCH 2
KGT-M71ST-00 STICKER, HEAD 1
90990-01J032 BOLT HEX. SOCKET HEAD 8
91312-03006 BOLT HEX. SOCKET HEAD 4
91312-04006 BOLT HEX. SOCKET HEAD 9
91312-04008 BOLT HEX. SOCKET HEAD 11
98902-03004 SCREW, BINDING HEAD 2
98902-04006 SCREW, BINDING HEAD 4
90990-11J003 SCREW, PAN HEAD W/W 6
$US10 JOINT 2
KKE-M2256-00 GRIP 1
$UL10 JOINT 2
91312-04020 BOLT HEX. SOCKET HEAD 2
91312-06012 BOLT HEX. SOCKET HEAD 1
90K63-611203 AC SERVO MOTOR 1
91312-06020 BOLT HEX. SOCKET HEAD 4
X-axis-I/O Box/ Plate A, B
KKE-M2231-00 FRAME, HEAD SERVO 1
KKE-M2235-00 COVER, I/O 1
KKE-M2236-00 STAY, DUCT 1
KKE-M2237-00 STAY, 3 1
KKE-M2238-01 BRACKET R 1 B-Table
KKE-M2238-50 BRACKET R 1 A-Table
KKE-M2239-00 PLATE, 1 2
KKE-M223A-00 STAY, R HNS. 1
KKE-M223B-00 STAY, L HNS. 1
KKE-M223C-00 STAY, B HNS. 1
KKE-M223H-00 STAY, CAMERA HNS. B 1 B-Table
KKE-M223G-00 STAY, CAMERA HNS. A 1 A-Table
KKE-M223M-00 STAY, JOINT 1 B-Table
KKE-M223P-00 PLATE, I/O 1
KKE-M223R-00 COVER 1
KKE-M223S-00 STAY, VAC HNS. 1
KKE-M223N-00 STAY, GRIP 1 B-Table
KKE-M223N-50 STAY, GRIP 1 A-Table
90990-01J050 BOLT HEX. SOCKET HEAD 6
91312-03006 BOLT HEX. SOCKET HEAD 13
91312-04006 BOLT HEX. SOCKET HEAD 23
91312-04010 BOLT HEX. SOCKET HEAD 6
91312-05014 BOLT HEX. SOCKET HEAD 8
91312-05020 BOLT HEX. SOCKET HEAD 4
97602-03306 SCREW, PAN HEAD W/W 3
98902-03004 SCREW, BINDING HEAD 2 B-Table
KKE-M2213-S0 PLATE XB AXIS SET 1 B-Table
KKE-M2213-S5 PLATE XA AXIS SET 1 A-Table
KV7-M2231-00 SPACER R, NUT 4
KHN-M22F8-00 WASHER,SWR08 16
91312-08025 BOLT HEX. SOCKET HEAD 16
KKE-M2238-10 BRACKET L 1 B-Table
KKE-M2238-60 BRACKET L 1 A-Table
X-axis-Sub Assy
KKE-M2211-00 FRAME B, X AXIS 1 B-Table
KKE-M2211-50 FRAME A, X AXIS 1 A-Table
KHY-M2240-00 SLEEVE, BRG. 1
KKE-M2241-00 HOLDER, MOTOR X 1
KHY-M2242-00 HOLDER, BRG. 1
KKE-M2271-00 BALL SCREW 1
KHY-M2276-S0 X-AXIS GUIDE SET 1
KHN-M2221-00 SUPPORT UNIT 1
KKE-M2261-A0 HOLDER, HEAD B ASSY. 1 B-Table
KKE-M2262-A0 HOLDER, HEAD A ASSY. 1 A-Table
KHY-M224H-00 DAMPER 2
KHN-M224D-00 SPACER 1
KHN-M2248-00 SPACER 2
KHN-M22F4-00 WASHER, SWR04 16
KHN-M22F6-00 WASHER, SWR06 8
KHN-M224J-00 COLLAR A 4
KHN-M224K-00 COLLAR B 4
KGS-M2628-00 LOCK NUT 1
KG2-M9173-00 LOCK NUT 1
KM0-M2220-00 COUPLING, X-AXIS 1
KHY-M220D-00 TAPE, X-AXIS 2
90990-26J008 BEARING 1
91312-04014 BOLT HEX. SOCKET HEAD 44
92012-04025 BOLT, BUTTON HEAD 4
91312-05016 BOLT HEX. SOCKET HEAD 4
91312-05018 BOLT HEX. SOCKET HEAD 4
91312-06025 BOLT HEX. SOCKET HEAD 8
92A08-04304 SCREW, SET 2
Y-axis-Cover/ Org Sensor
KKE-M26T4-00 COVER, LINEAR 1 2
KKE-M26T4-50 COVER, LINEAR 2 2
KKE-M26T5-00 COVER, LINEAR 3 4
90K41-000720 LABEL, ALERT 4
90K41-000860 STICKER, CAUTION 8
90K41-000990 STICKER, CAUTION 4
90990-46J010 BOLT, THIN HEAD 12
90990-46J011 BOLT, THIN HEAD 2
91380-04005 BOLT HEX. SOCKET HEAD 4
91380-05010 BOLT HEX. SOCKET HEAD 12
KKE-M2659-00 BRACKET, HANDLE 2
KH2-M1324-01 GRIP 2
91312-05010 BOLT HEX. SOCKET HEAD 4
91312-05014 BOLT HEX. SOCKET HEAD 4
KKE-M652A-00 SENSOR YAB ORG ASSY 2
KKE-M652B-00 SENSOR YAB OT ASSY 2
KKE-M2691-00 STAY, SENSOR 1
KKE-M2691-50 STAY, SENSOR 1
91312-04008 BOLT HEX. SOCKET HEAD 16
97602-03306 SCREW, PAN HEAD W/W 8
92902-03600 WASHER, PLAIN 4
KKE-M2682-00 DOG, ORIGIN 2
KKE-M2683-00 DOG, SECOND LIMIT 2
KKE-M2658-00 STOPPER 2
91312-05008 BOLT HEX. SOCKET HEAD 48
Y-axis-Stay/ Bracket/ Damper
KKE-M2654-00 PLATE , DAMPER 2
KKE-M2654-50 PLATE , DAMPER 2
KKE-M26F5-00 BRACKET, DAMPER 4
KHW-M2654-00 PLATE , DAMPER 4
KV7-M2651-00 DAMPER, STOPPER 12
KHW-M2656-00 SPACER 20
90563-24J370 SPACER BOLT 2
Delete MFY0027-2009/12/8
KKE-M26D8-50 COVER L, Y AXIS FAN 2
KKE-M2695-00 BRACKET GUIDE, Y AXIS 1
KKE-M2695-50 BRACKET GUIDE, Y AXIS 1
KKE-M652C-00 SENSOR Y SAFE ASSY 1
KKE-M2696-00 DOG, COL. 1
KKE-M2697-00 BRACKET, CON. B 1
KKE-M2697-50 BRACKET,CON. A 1
KKE-M2698-01 BRIDGE, HNS. B 1 NG MFY0018-2009/12/8
KKE-M2698-00 BRIDGE, HNS. 1
KKE-M2698-51 BRIDGE, HNS. A 1 NG MFY0018-2009/12/8
KKE-M2698-50 BRIDGE, HNS. 1
KKE-M269A-00 PLATE, HNS. B 1
KKE-M269A-50 PLATE, HNS. A 1
KKE-M269B-00 PLATE, HNS. B 1
KKE-M269B-50 PLATE, HNS. A 1
KKE-M26FD-00 BRACKET, DUCT 2
Delete MFY0027-2009/12/8
KKE-M26D8-00 COVER R, Y AXIS FAN 2
$US10 JOINT 4
97602-04306 SCREW, PAN HEAD W/W 2
KKE-M26T7-00 PLATE, BASE B 1
KKE-M26T7-50 PLATE, BASE A 1
KKE-M26T8-00 PLATE, CON. B 1
KKE-M26T8-50 PLATE, CON. A 1
KKE-M26T9-01 PLATE, CON. B 1 NG MFY0018-2009/12/8
KKE-M26T9-00 PLATE, CON. B 1
KKE-M26T9-51 PLATE, CON. A 1 NG MFY0018-2009/12/8
KKE-M26T9-50 PLATE, CON. A 1
KHN-M22F5-00 WASHER, SWR05 32
KKE-M26TF-00 PLATE, FAN 2
Delete MFY0027-2009/12/8
KKE-M26D6-00 DUCT 1 2
Delete MFY0027-2009/12/8
KKE-M26D6-50 DUCT 1 2
Delete MFY0027-2009/12/8
KKE-M26D7-00 DUCT 2 4
Delete MFY0027-2009/12/8
KKE-M26D9-B0 FAN MOTOR ASSY. 2
Delete MFY0027-2009/12/8
KKE-M26D9-A0 FAN MOTOR ASSY. 2
$NK-3N NYLON CLIP 6
90172-00J060 WASHER, EXTL. TOOTHED 8
90563-03J100 SPACER BOLT 8
Delete MFY0018-2009/12/8
90990-46J001 BOLT, THIN HEAD 4
91312-03006 BOLT HEX. SOCKET HEAD 56
91312-03008 BOLT HEX. SOCKET HEAD 2
91312-03010 BOLT HEX. SOCKET HEAD 8
91312-04006 BOLT HEX. SOCKET HEAD 18
91312-04008 BOLT HEX. SOCKET HEAD 40
91312-04010 BOLT HEX. SOCKET HEAD 10
91312-04012 BOLT HEX. SOCKET HEAD 12
92902-06200 WASHER, PLAIN 8
92902-04200 WASHER, PLAIN 2
91312-05014 BOLT HEX. SOCKET HEAD 6
91312-05016 BOLT HEX. SOCKET HEAD 32
91312-06012 BOLT HEX. SOCKET HEAD 8
Y-axis-Liner Motor/ Duct
KKE-M2611-S0 FRAME, Y AXIS SET 1
KKE-M2676-S0 GUIDE SET, Y AXIS 1
$NK-4N NYLON CLIP 4
99480-06012 PIN, PARALLEL 4
KHN-M2651-00 NYLOCK BOLT (M12X45) 22
KKE-M26F1-01 FRAME 1,L NG
KKE-M26F1-00 FRAME 1 2
KHY-M260B-00 TAPE, Y DUCT 2
KHY-M260C-00 TAPE 2, Y DUCT 2
KHY-M260D-00 TAPE 3, Y DUCT 2
KV7-M2266-00 PLATE, NUT 4
KHY-M2669-00 BRACKET, HARNESS 4
KHY-M2678-00 GUIDE, CABLE Y 2
97602-04308 SCREW, PAN HEAD W/W 4
90990-21J001 PIN 6
90172-00J060 WASHER, EXTL. TOOTHED 16
90201-124G9 WASHER, PLAIN 22
90990-01J032 BOLT HEX. SOCKET HEAD 16
97602-03310 SCREW, PAN HEAD W/W 56
91312-06012 BOLT HEX. SOCKET HEAD 16
92902-06200 WASHER, PLAIN 16
98502-03004 SCREW, PAN HEAD 8
KKE-M26CJ-01 MOTOR, Y AXIS 4
KKE-M26CJ-00 MOTOR, Y AXIS 4
KKE-M26C8-00 PLATE 1 4
KKE-M26CK-00 PLATE 2 4
KKE-M26CB-00 STATOR ASSY. 16
KKE-M26CL-02 FAN MOTOR ASSY 4
KKE-M26CF-01 BRACKET, FAN 4
KJ3-M4187-00 FAN GUARD 4
KKE-M26BS-00 FIN 16
KKE-M26BY-00 PLATE 4
91312-04006 BOLT HEX. SOCKET HEAD 8
91312-04018 BOLT HEX. SOCKET HEAD 16
91312-04020 BOLT HEX. SOCKET HEAD 4
91312-04025 BOLT HEX. SOCKET HEAD 4
91312-06020 BOLT HEX. SOCKET HEAD 40
91312-06075 BOLT HEX. SOCKET HEAD 144
91380-04030 BOLT HEX. SOCKET HEAD 16
92902-04600 WASHER, PLAIN 16
92902-06600 WASHER, PLAIN 39
KKE-M26T1-A0 TAPE, LINEAR SCALE 2
KKE-M26T2-00 HEAD, LINEAR SCALE 4
KKE-M26T6-00 HOLDER, SENSOR 4
$NK-3N NYLON CLIP 2
91312-03008 BOLT HEX. SOCKET HEAD 10
91312-04025 BOLT HEX. SOCKET HEAD 8
92902-04200 WASHER, PLAIN 10
97602-04306 SCREW, PAN HEAD W/W 8
98702-03006 SCREW, FLAT HEAD 8
92902-03600 WASHER, PLAIN 8
KKE-M26F2-00 FRAME 1,R 1 NG MG10030-2010/1/15
Body Head / Vision
KHY-M7117-00 STOPPER 1
KKE-M7118-00 PLATE, STOPPER 1
KKE-M71C1-00 BRACKET, RIGHT 1
KKE-M71C2-00 BRACKET, LEFT 1
KKE-M71C3-00 STAY, EJECTOR 1
KKE-M71C4-00 STAY, HOSE 1
KKE-M71C5-00 BRACKET, CABLE 1
KKE-M71C8-00 PLATE, HARNESS 1
KKE-M71C9-00 PLATE 2, HARNESS 1
90990-41J123 COLLAR 5
99480-04010 PIN PARALLEL: 4X10 4
$NK-3N NYLON CLIP 12
90990-11J003 SCREW, PAN HEAD W/W 5
91312-04006 BOLT HEX. SOCKET HEAD 20 M4X6
91312-04008 BOLT HEX. SOCKET HEAD 25 M4X8
KKE-M71B0-L0 VISION ATTACHMENT L 1
KKE-M71C7-00 STAY, LEFT 1
KHY-M71C8-00 COVER, CAMERA L 1
KKE-M71B0-R0 VISION ATTACHMENT R 1
KHY-M71B1-00 HOLDER, CAMERA 2
KHY-M71B2-00 SATY, FID. LIGHT 2
KHN-M7210-01 CCD CAMERA 2
KHY-M7211-00 LENS FID. 2
KHN-M7600-00 FIDUCIAL LIGHT ASSY. 2
KHY-M71C6-00 COVER, CAMERA R 1
KV7-M7165-00 SEAL DON’T TOUCH 2
90563-04J100 SPACER BOLT 2
$NK-2N NYLON CLIP 5
92902-03200 WASHER PLAIN 5
91312-03006 BOLT HEX. SOCKET HEAD 5 M3X6
91312-03016 BOLT HEX. SOCKET HEAD 4 M3X16
91312-04025 BOLT HEX. SOCKET HEAD 4 M4X25
91312-04045 BOLT HEX. SOCKET HEAD 4 M4X45
91312-05014 BOLT HEX. SOCKET HEAD 4
Body Head Sub
KHY-M7101-00 HOUSING, HEAD 1
KHY-M7113-00 PLATE 2, BRG. 1
KHY-M7114-00 PLATE 3, BRG. 8
90990-01J040 BOLT HEX. SOCKET HEAD 20
98702-03006 SCREW FLAT HEAD 11
91312-05035 BOLT HEX. SOCKET HEAD 4 M5X35
KKE-M7102-00 PLATE, R MOTOR 1
KKE-M7125-00 BRACKET, STOPPER 2
KKE-M7126-00 SHAFT 2, TENSION 2
KHY-M7127-00 BLOCK 1, ADJUST 2
KKE-M7128-00 SHAFT 3,TENSION 2
KHY-M7129-00 BLOCK 3, ADJUST 2
KHY-M7131-00 BELT 1 2
KHY-M7132-00 BELT 2 2
KHN-M7131-00 PULLY R MOTOR 2
KHN-M7132-00 BLOCK1 STOPPER 2
KKE-M7139-00 STOPPER R 2
KGV-M7157-00 BLOCK2, STOPPER R 2
KV8-M7115-00 SHAFT 1, TENSION 4
90K2A-045J11 AC SERVO MOTOR 1 OK MFX0002-2009/11/6
90K2A-046911 AC SERVO MOTOR 1
90K2A-04JF12 AC SERVO MOTOR 1
90933-03J128 BEARING 16
90990-19J016 NEEDLE, PIN 2
99009-07800 CIRCLIP : 2
99480-04008 PIN, PARALLEL: 4X8 2
$NK-3N NYLON CLIP 1
92902-03200 WASHER PLAIN 8
92902-04200 WASHER PLAIN 6
92A08-04304 SET SCREW M4X4 4
90990-11J003 SCREW, PAN HEAD W/W 1
91312-03008 BOLT HEX. SOCKET HEAD 4 M3X8
91312-03010 BOLT HEX. SOCKET HEAD 2 M3X10
91312-03012 BOLT HEX. SOCKET HEAD 8 M3X12
91312-03035 BOLT HEX. SOCKET HEAD 4 M3X35
91312-04006 BOLT HEX. SOCKET HEAD 4 M4X6
KKE-M7133-00 SHEET, SCREEN 1
KKE-M7134-00 PLATE, SCREEN 2
KKE-M7135-00 PLATE, SCREEN 2
91312-03006 BOLT HEX. SOCKET HEAD 4
91312-05020 BOLT HEX. SOCKET HEAD 2
Shaft Head Sub Assy
KKE-M7107-B0 HEAD SHAFT 2B ASSY. 5 OK MFX0123-2009/12/3
KKE-M7106-A0 HEAD SHAFT 1 ASSY. 5
KHY-M7107-00 BALL SPLINE 2 5 OK MFX0123-2009/12/3
KHY-M7106-00 BALL SPLINE 1 5
KKE-M7107-A0 HEAD SHAFT 2 ASSY. 5
KHY-M7107-00 BALL SPLINE 2 5
KHY-M7105-00 HOLDER, NOZZLE 10
KHY-M7108-00 COLLAR, BRG. 10
KKE-M7111-00 HOLDER, BEARING 10
KKE-M7112-00 PLATE 1, BRG. 10
KKE-M7115-00 BRACKET, JOINT 10
KHY-M7121-00 PULLEY, SHAFT 10
KHY-M7122-00 NUT, SHAFT 10
KHY-M7123-00 COLLAR, SHAFT 10
KG7-M7137-A0 LEAF SPRING 20
90990-02J005 SET SCREW M3X2 20
90990-08J016 SCREW, PAN HEAD 40
90990-15J003 NUT, HEXAGON 10
90990-17J053 O-RING 20
90990-22J009 PACKING 10
90933-02J104 BEARING 10
KKE-M7113-00 JOINT 10
$PF-M3 PLUG 10
91312-03006 BOLT HEX. SOCKET HEAD 20 M3X6
91312-03030 BOLT HEX. SOCKET HEAD 20 M3X6
91312-03008 BOLT HEX. SOCKET HEAD 10 M3X6
91312-03010 BOLT HEX. SOCKET HEAD 10 M3X30
Delete MFX0123-2009/12/3
KHY-M711S-A0 SHAFT 1, SPARE 1
KHY-M712S-A0 SHAFT 2, SPARE 1
KKE-M712B-00 SPRING, RETURN 10
KKE-M712C-00 COLLOR SPRING 10
KKE-M712K-00 GUIDE, SPRING 10
Ejector / Z-axis
KHY-M7151-01 EJECTOR, RESIN 1
KHY-M4592-01 VAC SENSOR BRD ASSY 1
KHY-M71CA-00 COVER,VAC SENSOR 1
90563-23J060 SPACER 4
91312-03005 BOLT HEX. SOCKET HEAD 6 M3X5
KHY-M7152-01 EJECTER 1
KHY-M7153-00 VALVE 1
KHY-M7154-01 BIT 1
KHY-M7155-00 FILTER CAP 1
KHY-M7156-01 BIT CAP 1
K46-M8527-C0 FILTER 1
90990-17J010 ORING 2
KKE-M71G5-A0 Z UNIT ASSY. 5
KKE-M71G5-A5 Z UNIT ASSY. 5
KKE-M71G1-00 SIDE PLATE, R 1
KKE-M71G2-00 SIDE PLATE, L 1
KHY-M71G3-00 SHAFT 1 2
KHY-M71H3-00 TAPE, Z-UNIT 1
90990-28J078 WASHER, PLAIN 4
91312-05014 BOLT HEX. SOCKET HEAD 8 M5X14
99480-04008 PIN, PARALLEL: 4X8 2
90K41-000720 LABEL, ALERT 2
$TL10-01 JOINT 2
Scan Camera / Axis
KKD-M78C0-00 SCAN CAM. ASSY 1
KHY-M7A13-01 DIFFUSER, MAIN 1
KHY-M7554-02 OF. LIGHT BRD. ASSY. 1
KHY-M7A30-00 SIDE LIGHT ASSY. 1
KV7-M7165-00 SEAL DON’T TOUCH 1
90990-08J026 SCREW, PAN HEAD 4
90112-02J006 BOLT HEX. SOCKET HEAD 2
KHY-M7A31-00 BLOCK, LIGHT SIDE 1
KHY-M7A34-00 DIFFUSER, SIDE 1
KHY-M7905-02 OF. SV. LIGHT BRD ASSY 1
90990-08J020 SCREW, M2X5 3
90990-28J002 WASHER PLAIN 3
KKE-M7850-00 SC MOTOR ASSY 1
KKE-M7880-00 HNS. SCAN ASSY 1
KKE-M7857-00 BRACKET, DUCT 1
KKE-M7865-00 PLATE, CABLE 1
KKE-M7866-00 BRACKET, CONNECTOR 1
KKE-M7892-01 BRACKET, CONNECTOR 1
KKE-M7893-00 PLATE, CLAMP 1
KKE-M7894-00 CLAMP, CABLE 1
KKE-M7896-00 COVER, SENSOR 1
KKE-M7897-00 COVER, CABLE 1
KKE-M66JA-00 HNS, SCAN FLEX 1
KHY-M7A98-00 TAPE, SCAN CABLE 1
91312-03006 BOLT HEX. SOCKET HEAD 14
91312-04006 BOLT HEX. SOCKET HEAD 8
98902-04005 SCREW, BINDING HEAD 4
98902-04008 SCREW, BINDING HEAD 2
90172-00J040 WASHER, EXTL. TOOTHED 1
$NK-2N NYLON CLIP 5
Nozzle
KHN-M7710-A2 NOZZLE 301A ASSY. 1 TYPE 301A
KHN-M7711-03 BODY, NOZZLE 301 1
KHN-M7713-00 SPRING 1
KHN-M7714-00 PIN 1
KHN-M7715-00 CLIP 1
KHN-M7720-A1 NOZZLE 302A ASSY. 1 TYPE 302A
KHN-M7721-02 BODY, NOZZLE 302 1
KHY-M7740-A0 NOZZLE 303A/314A ASSY. 1 TYPE 303A/314A
KHY-M7741-00 BODY, NOZZLE 303/314 1
KHY-M7750-A0 NOZZLE 304A/315A ASSY. 1 TYPE 304A/315A
90990-17J013 O-RING 5
KHY-M7770-A0 NOZZLE 306A/317A ASSY. 1 TYPE 306A/317A
KHY-M7771-00 BODY, NOZZLE 306/317 1
KHY-M77A0-A0 NOZZLE 310A ASSY. 1 TYPE 310A
KHY-M77A1-00 BODY, NOZZLE 310 1
KHY-M7710-A2 NOZZLE 311A ASSY. 1 TYPE 311A NG MFX0107-2010/1/28
KHY-M7710-A1 NOZZLE 311A ASSY. 1 TYPE 311A
KHY-M7711-01 BODY, NOZZLE 311 1 NG MFX0107-2010/1/28
KHY-M7711-00 BODY, NOZZLE 311 1
KHN-M7713-10 SPRING 1
KHY-M7720-A1 NOZZLE 312A ASSY. 1 TYPE 312A
KHY-M7721-00 BODY, NOZZLE 312 1
KHY-M7730-A0 NOZZLE 313A ASSY. 1 TYPE 313A
KHY-M7731-00 BODY, NOZZLE 313 1
Nozzle Changer
KKE-M9610-00 BOARD, CLEAR 1
KHY-M9622-03 PLATE, LED SHIELD 1
KKE-M9622-00 PLATE, LED2 SHIELD 1
$NK-3N NYLON CLIP 19
90112-2AJ008 BOLT HEX. SOCKET HEAD 3
90112-2AJ012 BOLT HEX. SOCKET HEAD 5
91312-04025 BOLT HEX. SOCKET HEAD 6
91312-06030 BOLT HEX. SOCKET HEAD 2
92902-06200 WASHER, PLAIN 2
97602-04308 SCREW, PAN HEAD W/W 19
KKE-M9603-00 BOTTOM HOLDER ASSY. 1
KKE-M9619-00 PLATE, BRACKET 1
KKE-M961C-00 BASE, A.N.C. 1
KHY-M9613-00 BLOCK, CYLINDER 1
KHY-M9614-00 STOPPER, CYLINDER 1
KHY-M9615-00 PLATE, CYLINDER 1
KHY-M9627-00 BLOCK, LINK 1
KHY-M9628-00 COLLAR, LINK 1
KHY-M9631-00 COLLAR, FLOATING 1
KHY-M9632-00 BLOCK, FLOATING 1
KHW-M916A-00 BUSH 2
KHW-M916E-00 BUSH 1
KHW-M916G-00 COLLAR, JOINT 1
KHW-M916H-00 JOINT, CYL. 1
KKE-M652J-00 CYLINDER ANC ASSY 1
$SC4-M5A SPEED CONTROLLER 2
91312-03010 BOLT HEX. SOCKET HEAD 2
91312-03025 BOLT HEX. SOCKET HEAD 2
91312-04022 BOLT HEX. SOCKET HEAD 1
92902-05200 WASHER, PLAIN 1
91312-05020 BOLT HEX. SOCKET HEAD 1
90933-02J063 BEARING 2
92902-04200 WASHER, PLAIN 3
91312-04012 BOLT HEX. SOCKET HEAD 2
91312-04016 BOLT HEX. SOCKET HEAD 1
90990-41J129 COLLAR 4
91312-04020 BOLT HEX. SOCKET HEAD 7
KKE-M9601-00 NOZZLE HOLDER ASSY. 1
KKE-M9605-00 MIRROR, CENTER 1
KKE-M9606-00 MIRROR, SIDE 4
KKE-M9607-00 PLATE, CLAMP 1
KKE-M9608-00 PIN, SLIDE 4
KKE-M9611-00 GUIDE SHEET, CLAMP 2
KHY-M9621-A0 BASE, NOZZLE D ASSY. 4
KHY-M9630-00 HOOK, BEARING 1
91312-03010 BOLT HEX. SOCKET HEAD 4
91312-03012 BOLT HEX. SOCKET HEAD 12
98902-03008 SCREW, BINDING HEAD 16
92012-04010 BOLT, BUTTON HEAD 2
KHY-M45BA-01 ANC CTRL BOARD ASSY 2
KHW-M8582-40 VALVE 1
Push-Up 1
KKE-M920A-00 PLATE 1 (320×440) 1
KKE-M920B-00 STAY 1
KKE-M9211-00 HOLDER, BRG. 3
KKE-M9212-00 HOUSING 3
KKE-M9218-00 GROMMET 1
KKE-M921A-00 BRKT., TENSIONER 1
KKE-M921D-00 BELT 291-3GT-15 1
KKE-M921F-00 BELT 927-3GT-15 1
KKE-M921S-00 BRKT., MOTOR 1
KKE-M9222-00 POST 1
KKE-M9224-00 COVER, PU MOTOR 1
KKE-M9B00-00 BALL SCREW PU 3
KKE-M652L-00 SENSOR 1-1 1
KGA-M921T-00 BOLT 4
KHW-M9215-00 PULLEY: P60-3GT 3
KHW-M921B-00 STAY, ADJUST 1
KHW-M921C-00 SHAFT 1 1
KHW-M921K-00 BRKT., SENSOR 1
KHW-M9223-00 PULLEY: P40-3GT 1
KHY-M921G-01 BRKT., DOG 1
KHY-M921H-01 PLATE, DOG 1
KHY-M921M-01 WASHER 3
KHY-M921N-01 JOINT A 3
KV7-M9205-01 PULLEY 1: P22-3GT 1
KV7-M9219-00 STOPPER 1
90440-01J090 CIRCLIP 3
90933-01J001 BEARING 2
90933-01J007 BEARING 6
90933-01J300 BEARING 2
90990-28J076 WASHER, PLAIN 1
90990-33J011 BOLT, STOPPER 1
90K63-331H25 AC SERVO MOTOR 1
91312-03005 BOLT HEX. SOCKET HEAD 2
91312-04006 BOLT HEX. SOCKET HEAD 9
91312-04008 BOLT HEX. SOCKET HEAD 4
91312-04010 BOLT HEX. SOCKET HEAD 11
91312-04012 BOLT HEX. SOCKET HEAD 14
91312-04020 BOLT HEX. SOCKET HEAD 1
91312-05010 BOLT HEX. SOCKET HEAD 17
91312-05012 BOLT HEX. SOCKET HEAD 8
91312-05016 BOLT HEX. SOCKET HEAD 12
91312-05020 BOLT HEX. SOCKET HEAD 1
92902-04200 WASHER, PLAIN 4
92902-05200 WASHER, PLAIN 18
95302-04600 NUT, HEXAGON 1
95602-10100 NUT, U 4
99009-10400 CIRCLIP 1
99009-12400 CIRCLIP 1
KHY-M920D-00 PUSH UP PIN UNIT 10
Push-Up 2
KKE-M920A-10 PLATE 1 (320×303) 2
KKE-M920B-10 STAY 1
KKE-M9211-00 HOLDER, BRG. 3
KKE-M9212-00 HOUSING 3
KKE-M9218-00 GROMMET 1
KKE-M9219-00 STOPPER 3
KKE-M921A-00 BRKT., TENSIONER 1
KKE-M921D-00 BELT 291-3GT-15 1
KKE-M921E-00 BELT 1335-3GT-15 1
KKE-M921H-00 PLATE, DOG 1
KKE-M921S-00 BRKT., MOTOR 1
KKE-M9222-00 POST 1
KKE-M9224-00 COVER, PU MOTOR 1
KKE-M9B00-00 BALL SCREW PU 3
KKE-M652L-10 SENSOR PU2 ORG ASSY 1
KGA-M921T-00 BOLT 8
KHW-M9215-00 PULLEY: P60-3GT 3
KHW-M921B-00 STAY, ADJUST 1
KHW-M921C-00 SHAFT 1 1
KHY-M921G-01 BRKT., DOG 1
KHW-M921K-00 BRKT., SENSOR 1
KHW-M9223-00 PULLEY: P40-3GT 1
KHY-M921M-01 WASHER 3
KHY-M921N-01 JOINT A 3
KV7-M9205-01 PULLEY 1: P22-3GT 1
90440-01J090 CIRCLIP 3
90933-01J001 BEARING 2
90933-01J007 BEARING 6
90933-01J300 BEARING 2
90990-28J076 WASHER, PLAIN 1
90990-33J011 BOLT, STOPPER 3
90K63-331H26 AC SERVO MOTOR 1
91312-03005 BOLT HEX. SOCKET HEAD 2
91312-04006 BOLT HEX. SOCKET HEAD 9
91312-04008 BOLT HEX. SOCKET HEAD 4
91312-04010 BOLT HEX. SOCKET HEAD 11
91312-04012 BOLT HEX. SOCKET HEAD 18
91312-04020 BOLT HEX. SOCKET HEAD 1
91312-05010 BOLT HEX. SOCKET HEAD 21
91312-05012 BOLT HEX. SOCKET HEAD 8
91312-05016 BOLT HEX. SOCKET HEAD 12
91312-05020 BOLT HEX. SOCKET HEAD 1
92902-04200 WASHER, PLAIN 4
92902-05200 WASHER, PLAIN 18
95302-04600 NUT, HEXAGON 1
95602-10100 NUT, U 8
99009-10400 CIRCLIP 1
99009-12400 CIRCLIP 1
KHY-M920D-00 PUSH UP PIN UNIT 10
Main Stopper
KKE-M9161-00 BRKT., CYLINDER 1
KKE-M9162-00 BRKT., CYLINDER 2
KKE-M9163-00 BRKT., STOPPER 1
KKE-M9164-00 BRKT., STOPPER 2
KKE-M9165-00 PLATE, STOPPER 3
KKE-M9167-00 PLATE, STOPPER 1
KKE-M9168-00 PLATE, STOPPER 2
KKE-M9169-00 SHAFT, STOPPER 3
KKE-M916B-00 GUIDE 3
KKE-M653A-00 CYLINDER, MAIN 1 ASSY. 1
KHW-M916C-00 SPACER 6
KHW-M916G-00 COLLAR, JOINT 3
KHW-M916H-00 JOINT, CYL. 3
90990-08J027 SCREW, PAN HEAD 6
$UEF4BU-M3 JOINT 6
90112-2AJ006 BOLT HEX. SOCKET HEAD 2
90112-2AJ005 BOLT HEX. SOCKET HEAD 4
91312-03006 BOLT HEX. SOCKET HEAD 6
91312-04006 BOLT HEX. SOCKET HEAD 4
91312-04006 BOLT HEX. SOCKET HEAD 2
91312-04010 BOLT HEX. SOCKET HEAD 5 MAIN 1
91312-04010 BOLT HEX. SOCKET HEAD 4 MAIN 2-1, 2-2
92012-04010 BOLT, BUTTON HEAD 4 MAIN 2-1, 2-2
92012-04012 BOLT, BUTTON HEAD 1 MAIN 1
92902-04600 WASHER, PLAIN 6
91312-04012 BOLT HEX. SOCKET HEAD 2
KKE-M653B-00 CYLINDER, MAIN 2-1 ASSY. 1
KKE-M653C-10 CYLINDER, MAIN 2-2 ASSY. 1 OK MFX0146-2009/12/17
KKE-M653C-00 CYLINDER, MAIN 2-2 ASSY. 1
KKE-M9161-10 BRKT., CYLINDER 1
Sub Stopper / Exit Stopper
KKE-M9271-00 BRKT., CYLINDER 1 R>L
KKE-M9281-00 BRKT., CYLINDER 1 R>L
KKE-M653D-00 CYLINDER SUB ST ASSY 1
KHW-M9274-A0 SPEED CONTROLLER 4
KKE-M9275-00 BRKT., SENSOR 1 R>L
KHW-M9272-00 STOPPER, EXIT 1
KHY-M9273-00 CYLINDER 1
KHW-M9282-00 STOPPER, SUB 1
KHY-M9284-00 PLATE, STOPPER 2
91312-04006 BOLT HEX. SOCKET HEAD 4
91312-04006 BOLT HEX. SOCKET HEAD 2
91312-05010 BOLT HEX. SOCKET HEAD 4
91312-05014 BOLT HEX. SOCKET HEAD 4
92902-04200 WASHER, PLAIN 2
KKE-M9271-10 BRKT., CYLINDER 1 L>R
KKE-M9275-10 BRKT., SENSOR 1 L>R
Clamp Board-1
KKE-M9262-00 PLATE, BASE S 2
KKE-M9268-00 BRKT., CYL. 1
KKE-M926C-00 PLATE, BOARD CLAMP 2
KKE-M926F-00 COLLAR, FLOATING 2
KKE-M926G-00 PLATE 2, LINK 2
KKE-M926H-00 PLATE 1 1
KHW-M9167-00 BRKT., CYL. 2
KHW-M916E-00 BUSH 2
KHW-M9261-00 PLATE1, LINK 4
KHW-M9264-B0 LINK B ASSY. 2
KHW-M9265-00 SPACER 8
KHW-M926A-00 COLLAR 4
KHW-M926B-00 COLLAR, JOINT 2
KHW-M926E-00 NUT 2
KHW-M9285-00 SPEED CONTROLLER 4
KHY-M9263-00 CYLINDER 2
KHY-M926F-00 JOINT, CYL. BRKT 2
KHY-M926H-00 JOINT, CYL. 2
KHY-M926M-00 STOPPER, CYLINDER 2
KV7-M9266-01 GUIDE 6
90169-02JB04 SCREW, BINDING HEAD 24
91312-04006 BOLT HEX. SOCKET HEAD 2
90563-04J170 SPACER BOLT 2
91312-04005 BOLT HEX. SOCKET HEAD 2
91312-04010 BOLT HEX. SOCKET HEAD 2
91312-04012 BOLT HEX. SOCKET HEAD 10
91312-04014 BOLT HEX. SOCKET HEAD 8
91312-04016 BOLT HEX. SOCKET HEAD 2
92012-04012 BOLT, BUTTON HEAD 2
92902-04200 WASHER, PLAIN 2
95302-06600 NUT, HEXAGON 2
98902-03005 SCREW, BINDING HEAD 8
KKE-M9269-00 BRKT., CYL. 1
KKE-M926J-00 PLATE 1 1
KHW-M9264-A0 LINK A ASSY. 2
Clamp Board-2
KKE-M9262-00 PLATE, BASE S 2
KKE-M9269-00 BRKT., CYL. 2
KKE-M926D-00 PLATE, BOARD CLAMP 2
KKE-M926F-00 COLLAR, FLOATING 2
KKE-M926G-00 PLATE 2, LINK 2
KKE-M926J-00 PLATE 1 2
KHW-M9167-00 BRKT., CYL. 2
KHW-M916E-00 BUSH 2
KHW-M9261-00 PLATE1, LINK 4
KHW-M9264-B0 LINK B ASSY. 2
KHW-M9265-00 SPACER 8
KHW-M926A-00 COLLAR 4
KHW-M926B-00 COLLAR, JOINT 2
KHW-M926E-00 NUT 2
KHW-M9285-00 SPEED CONTROLLER 4
KHY-M9263-00 CYLINDER 2
KHY-M926F-00 JOINT , CYL. BRKT 2
KHY-M926H-00 JOINT, CYL. 2
KHY-M926M-00 STOPPER, CYLINDER 2
KV7-M9266-01 GUIDE 6
90169-02JB04 SCREW, BINDING HEAD 24
90563-04J170 SPACER BOLT 4
91312-04005 BOLT HEX. SOCKET HEAD 4
91312-04010 BOLT HEX. SOCKET HEAD 2
91312-04012 BOLT HEX. SOCKET HEAD 10
91312-04014 BOLT HEX. SOCKET HEAD 8
91312-04016 BOLT HEX. SOCKET HEAD 2
92012-04012 BOLT, BUTTON HEAD 2
92902-04200 WASHER, PLAIN 2
95302-06600 NUT, HEXAGON 2
98902-03005 SCREW, BINDING HEAD 8
KHW-M9264-A0 LINK A ASSY. 2
Main Conveyor Sub Assy A-1
KKE-M9103-00 PLATE A 2
KKE-M9104-00 PLATE B 1
KKE-M9105-00 PLATE C 1
KKT-M9118-00 STAND, DUMP BOX 1 Depth 8mm NG MG20027-2010/2/9
KKE-M9110-00 STAND, DUMP BOX 1 Depth 11mm
KKE-M9115-00 GUIDE D 1
KKE-M9116-00 LM RAIL & BLOCK 15, 510 2
KKE-M9121-01 FRAME, CONVEYOR 2 1250mm L=619 NG MFX0132-2009/12/4
KKE-M9121-00 FRAME, CONVEYOR 2 1250mm L=619
KKE-M9122-02 PLATE 2D, GUIDE 2 NG MFX0132-2009/12/4
KKE-M9122-01 PLATE 2D, GUIDE 2
KKE-M9123-02 PLATE 1B, GUIDE 2 NG MFX0132-2009/12/4
KKE-M9123-01 PLATE 1B, GUIDE 2
KKE-M9131-00 PLATE, HNS. 1
KKE-M9186-00 PLATE 2, GUIDE 2
KKE-M919B-00 GUIDE B 1
KKE-M919J-00 PLATE, SENSOR 1
KKE-M919K-00 PLATE, DOG 1
KKE-M919U-00 DAMPER A 1
KKE-M9A00-00 BALL SCREW W 2
KKE-M652M-00 SENSOR W1 ORG ASSY 1
KGA-M9113-00 GUIDE 1, END 1 (L>R back side)
KGA-M9114-00 GUIDE 2, END 1 (L>R front side)
91312-04008 BOLT HEX. SOCKET HEAD 6
KHY-M9154-00 SPACER 1
KHY-M9620-00 PIN, MARK 1
91312-03005 BOLT HEX. SOCKET HEAD 2
91312-03006 BOLT HEX. SOCKET HEAD 14
91312-04016 BOLT HEX. SOCKET HEAD 8
91312-06016 BOLT HEX. SOCKET HEAD 1
92902-04600 WASHER, PLAIN 2
KKE-M9104-10 PLATE B 1 L>R
KKE-M9105-10 PLATE C 1 L>R
KKE-M9115-10 GUIDE D 1 L>R
KKE-M919B-10 GUIDE C 1 L>R
KKE-M9121-51 FRAME, CONVEYOR 2 1540mm L=774 NG MFX0132-2009/12/4
KKE-M9121-50 FRAME, CONVEYOR 2 1540mm L=774
KKE-M9124-00 PLATE 2, GUIDE 2 1540mm
KKE-M9125-00 GUIDE 1-1 2 1540mm
91312-05010 BOLT HEX. SOCKET HEAD 2
97602-04306 SCREW, PAN HEAD W/W 13
91312-03008 BOLT HEX. SOCKET HEAD 12 1540mm
92902-03200 WASHER PLAIN 6 1540mm
KH2-M9121-00 BEARING 2
91312-04006 BOLT HEX. SOCKET HEAD 6
92902-04200 WASHER, PLAIN 1
91312-03008 BOLT HEX. SOCKET HEAD 16
$NK-2N NYLON CLIP 13
91312-04012 BOLT HEX. SOCKET HEAD 10
91312-04014 BOLT HEX. SOCKET HEAD 27
91312-06012 BOLT HEX. SOCKET HEAD 12
Main Conveyor Sub Assy A-2
KKE-M9101-00 PLATE 1 2
KKE-M9102-00 PLATE A 2
KKE-M9106-00 BRKT., STOPPER 1
KKE-M9107-01 SHAFT 1
KKE-M919C-00 PULLEY 1
KKE-M9111-00 BRKT., MOTOR W 1
KKE-M9112-01 PLATE 2, TENSIONER 1
KKE-M9126-00 DAMPER A 1
KKE-M9129-00 BELT 882-3GT-9 1
KKE-M9143-A0 PULLEY ASSY. 1
KKE-M918K-00 BRKT. 2, TENSIONER 1
KKE-M9132-00 BRKT. 1, TENSIONER 1
KKE-M918T-00 SHAFT 1
KG7-M9111-01 PULLEY 1 1
KG7-M9112-01 PULLEY 2 1
KG7-M9113-01 PULLEY 3 1
KHW-M9139-00 PLATE, BRG. 2
90933-01J001 BEARING 2
90933-01J200 BEARING 2
90933-03J608 BEARING 2
90990-28J076 WASHER, PLAIN 2
90990-28J082 WASHER, PLAIN 1
90990-41J006 COLLAR 2
90K63-201443 AC SERVO MOTOR 1
91312-03008 BOLT HEX. SOCKET HEAD 8
91312-04012 BOLT HEX. SOCKET HEAD 2
91312-04040 BOLT HEX. SOCKET HEAD 1
91312-05035 BOLT HEX. SOCKET HEAD 1
91312-06012 BOLT HEX. SOCKET HEAD 4
91312-06025 BOLT HEX. SOCKET HEAD 12
91312-06060 BOLT HEX. SOCKET HEAD 4
91312-05030 BOLT HEX. SOCKET HEAD 1
KKE-M9132-A0 TENSIONER 1 ASSY 1
97002-05035 BOLT HEXGON 1
KKE-M9108-00 COVER, PULLEY 1
KKE-M9106-10 BRKT., STOPPER 1 L>R
KKE-M9108-10 COVER, PULLEY 1 L>R
KKE-M9111-10 BRKT., MOTOR W 1 L>R
91312-05006 BOLT HEX. SOCKET HEAD 2
91312-04008 BOLT HEX. SOCKET HEAD 12
91312-05010 BOLT HEX. SOCKET HEAD 8
92902-04200 WASHER, PLAIN 8
92902-05200 WASHER, PLAIN 14
92A08-04303 SCREW, SET 8
KHY-M9152-00 SPACER 1
Main Conveyor Sub Assy A-3
KKE-M9109-00 BRKT., CONV. MOTOR 1
KKE-M9114-00 BRKT. 2, SPLINE 1
KKE-M9117-00 SPLINE 1 1
KKE-M9118-00 BRACKET, COLLAR 1
KKE-M9119-A0 PULLEY CONV. ASSY. 2
KKE-M9120-A0 PULLEY CONV. ASSY 2
KKE-M9127-00 BELT 1, CONVEYOR 2 1250mm L=1400mm
KKE-M9128-00 BELT 222-3GT-9 1
KG2-M9108-11 COLLAR CONVEYOR 1
KGK-M9170-00 DC MOTOR ASSY. 1
KGT-M9135-00 PULLEY 1, SPLINE 1
KGT-M915U-00 PULLEY DRIVE, F 1
KGT-M9193-00 NUT PLATE 4
KGY-M9140-A0 PULLEY, CONV. ASSY 4
KH2-M9105-11 PULLEY, MOTOR:P30- 2
KH2-M9121-00 BEARING 2
KHY-M912A-00 BRKT., SENSOR 1
KKE-M9135-00 PLATE, EDGE 2 8
KV1-M9140-A0 PULLEY CONV. ASSY. 2
90990-28J070 WASHER, PLAIN 1
91312-03010 BOLT HEX. SOCKET HEAD 4
91312-04006 BOLT HEX. SOCKET HEAD 2
91312-04008 BOLT HEX. SOCKET HEAD 5
91312-04010 BOLT HEX. SOCKET HEAD 3
91312-04055 BOLT HEX. SOCKET HEAD 4
91312-05006 BOLT HEX. SOCKET HEAD 2
91312-05010 BOLT HEX. SOCKET HEAD 2
91312-05020 BOLT HEX. SOCKET HEAD 2
92902-04200 WASHER, PLAIN 6
92902-05200 WASHER, PLAIN 10
92902-05600 WASHER, PLAIN 4
92A08-04303 SCREW, SET 4
98702-03005 SCREW, FLAT HEAD 16
KKE-M9109-10 BRKT., CONV. MOTOR 1 L>R
KKE-M9127-50 BELT 1, CONVEYOR 2 1540mm L=1710mm
KKE-M9113-00 BRKT.1, SPLINE 1
90990-41J006 COLLAR 1
91312-04005 BOLT HEX. SOCKET HEAD 2
91312-04008 BOLT HEX. SOCKET HEAD 2
Main Conveyor Sub Assy B-1
KKE-M918P-00 BRACKET, DOG 1
KKE-M918W-10 COVER, HNS. 1 L>R MFX0146-2009/12/17
KKE-M918W-00 COVER, HNS. 1 R>L
KKE-M9191-00 FRAME, CONVEYOR 1
KKE-M9192-00 PLATE 1, GUIDE 1
KKE-M919K-00 PLATE, DOG 1
KKE-M919L-00 GUIDE, HNS. 1
KKE-M919V-00 DAMPER B 1
KHY-M9152-00 SPACER 1
90990-46J006 BOLT, THIN HEAD 3
91312-03008 BOLT HEX. SOCKET HEAD 5
91312-04006 BOLT HEX. SOCKET HEAD 13
91312-04008 BOLT HEX. SOCKET HEAD 4
91312-04035 BOLT HEX. SOCKET HEAD 1
92012-04008 BOLT, BUTTON HEAD 3
91312-05010 BOLT HEX. SOCKET HEAD 7
91312-05012 BOLT HEX. SOCKET HEAD 8
91312-06008 BOLT HEX. SOCKET HEAD 2
92902-05200 WASHER, PLAIN 2
92902-04600 WASHER, PLAIN 1
KKE-M918P-10 BRACKET DOG 1 L>R
KKE-M919L-10 GUIDE, HNS. 1 L>R
91312-04010 BOLT HEX. SOCKET HEAD 8
KKE-M9181-00 HOLDER 1, BRG. 2
KKE-M9184-00 HOLDER A, BRG. 1
KKE-M9184-10 HOLDER B, BRG. 1
KKE-M9188-00 PLATE 2
KKE-M9189-00 HOLDER 2, NUT 2
KKE-M918A-00 PLATE, NUT 4
KKE-M918J-00 BRKT., U MOTOR 1
KKE-M918K-00 BRKT.2, TENSIONER 1
KKE-M919X-00 BRKT. 1, TENSIONER 1
KKE-M918T-00 SHAFT 1
KKE-M9194-00 PLATE 2, GUIDE 1
KKE-M9195-00 PLATE 2, GUIDE 1
KKE-M9197-00 PULLEY: P30-3GT 2
KKE-M9198-00 PULLEY: P30-3GT 1
KKE-M9199-00 BELT 900-3GT-9 1
KKE-M919A-00 BALL SCREW 2
KKE-M919B-00 GUIDE B 1
KKE-M919B-10 GUIDE C 1
KKE-M919C-00 COLLAR 2, BRG. 4
KKE-M919G-01 BRKT. 2, DUCT 1 NG MFX0060-2009/11/26
KKE-M919G-00 BRKT. 2, DUCT 1
KKE-M919N-00 BRKT., HNS. 1
KKE-M919P-00 COVER, PULLEY 1
KKE-M919S-00 GUIDE, HNS. 1
KKE-M919U-00 DAMPER A 1
KG2-M2604-00 SUPPORT UNIT 2
KHY-M9154-00 SPACER 1
KHY-M9620-00 PIN, MARK 1
90933-01J001 BEARING 2
90K63-311558 AC SERVO MOTOR 1
90933-03J608 BEARING 1
92902-05200 WASHER, PLAIN 1
90990-28J076 WASHER, PLAIN 1
90990-28J082 WASHER, PLAIN 1
91312-04005 BOLT HEX. SOCKET HEAD 2
91312-04012 BOLT HEX. SOCKET HEAD 6
91312-04014 BOLT HEX. SOCKET HEAD 1
91312-05008 BOLT HEX. SOCKET HEAD 2
91312-05030 BOLT HEX. SOCKET HEAD 9
97002-05035 BOLT 1
91312-06012 BOLT HEX. SOCKET HEAD 6
91312-06020 BOLT HEX. SOCKET HEAD 8
91312-06100 BOLT HEX. SOCKET HEAD 4
KKE-M918J-10 BRKT., U MOTOR 1 L>R
KKE-M919G-11 BRKT.2, DUCT 1 L>R NG MFX0060-2009/11/26
KKE-M919G-10 BRKT.3, DUCT 2 L>R
KKE-M919P-10 COVER, PULLEY 1 L>R
KKE-M919S-10 GUIDE, HNS 1 L>R
92902-05200 WASHER, PLAIN 2 L>R
92902-04200 WASHER, PLAIN 2
91312-03006 BOLT HEX. SOCKET HEAD 6
KKE-M919X-A0 TENSHIONER 2 ASSY 1
Main Conveyor Sub Assy B-2
KKE-M9180-00 LM RAIL & BLOCK 15, 720 2
KKE-M9182-00 HOLDER 2, BRG. 2
KKE-M9183-00 STAY 1 2
KKE-M9185-00 PLATE 1, GUIDE 2
KKE-M9186-00 PLATE 2, GUIDE 2
KKE-M9188-00 PLATE 2
KKE-M918B-00 HOLDER 1, NUT 2
KKE-M918C-00 PLATE 1, BRG. 2
KKE-M918D-00 PLATE, PULLEY 1
KKE-M918E-00 PULLEY: P50-3GT 2
KKE-M918F-00 SPACER 2
KKE-M918G-00 SLEEVE 2
KKE-M918H-00 PULLEY: P25-3GT 1
KKE-M918M-00 COVER 1, CABLE 1
KKE-M918V-01 BRKT., W MOTOR 1
KKE-M9193-00 PLATE 2, GUIDE 1
KKE-M919B-00 GUIDE B 1
KKE-M919B-10 GUIDE C 1
KKE-M919C-00 COLLAR 2, BRG. 4
KKE-M919T-00 BELT 1722-3GT-9 1
KKE-M919W-00 DAMPER C 1
KKE-M9143-A0 PULLEY ASSY. 3
KHY-M9620-00 PIN, MARK 1
90K63-001144 AC SERVO MOTOR 1
90933-03J608 BEARING 8
90933-01J807 BEARING 4
91312-03006 BOLT HEX. SOCKET HEAD 6
91312-04012 BOLT HEX. SOCKET HEAD 26
91312-04014 BOLT HEX. SOCKET HEAD 32
91312-05008 BOLT HEX. SOCKET HEAD 8
91312-05030 BOLT HEX. SOCKET HEAD 4
91312-06012 BOLT HEX. SOCKET HEAD 2
91312-06020 BOLT HEX. SOCKET HEAD 4
91312-06025 BOLT HEX. SOCKET HEAD 8
KKE-M918M-10 COVER.1, CABLE 1 L>R
KKE-M918V-11 BRKT., W MOTOR 1 L>R
91312-04006 BOLT HEX. SOCKET HEAD 8
KKE-M9187-00 PLATE 3, GUIDE 2
KKE-M918S-01 COVER, DUCT 1 NG MFX0060-2009/11/26
KKE-M918S-00 COVER, DUCT 2
KKE-M918U-00 DUCT, CABLE 1
KKE-M9191-00 FRAME, CONVEYOR 1
KKE-M9192-00 PLATE 1, GUIDE 1
KKE-M919E-01 BRKT. 1, DUCT 1 NG MFX0060-2009/11/26
KKE-M919E-00 BRKT. 1, DUCT 1
KKE-M919F-00 DUCT, CABLE 1
KKE-M919H-00 BRKT. 3, DUCT 1
KKE-M919J-00 PLATE, SENSOR 2
KKE-M919K-00 PLATE, DOG 1
KKE-M919M-01 COVER, HNS. 1
KKE-M652M-10 SENSOR W2 ORG ASSY 1
KKE-M652N-00 SENSOR U2 ORG ASSY 1
90990-46J010 BOLT, THIN HEAD 2
91312-03005 BOLT HEX. SOCKET HEAD 4
91312-03008 BOLT HEX. SOCKET HEAD 5
91312-04006 BOLT HEX. SOCKET HEAD 4
91312-04008 BOLT HEX. SOCKET HEAD 1
91312-05010 BOLT HEX. SOCKET HEAD 3
91312-05012 BOLT HEX. SOCKET HEAD 12
92012-05010 BOLT, BUTTON HEAD 4
92902-05200 WASHER, PLAIN 10
92902-04600 WASHER, PLAIN 3
98702-03005 SCREW, FLAT HEAD 8
98702-06008 SCREW, FLAT HEAD 4
KKE-M919E-11 BRKT. 1, DUCT 1 L>R NG MFX0060-2009/11/26
KKE-M919E-10 BRKT. 1, DUCT 1 L>R
KKE-M919M-11 COVER, HNS. 1 L>R
91312-03010 BOLT HEX. SOCKET HEAD 4
92A08-04303 SCREW, SET 1
Main Conveyor Sub Assy B-3
KKE-M918L-00 BRKT. 1, SPLINE 1
KKE-M918N-00 BRACKET 1, COLLAR 2
KKE-M918X-00 SPLINE 1 1
KKE-M918Y-00 SHAFT 1
KKE-M9196-00 BRKT., CONV. MOTOR 1
KKE-M919D-01 GUIDE, HNS. 1
KKE-M919R-00 BELT, CONVEYOR 2
KKE-M9119-A0 PULLEY CONV. ASSY. 6
KKE-M9128-00 BELT 222-3GT-9 1
KG2-M9108-11 COLLAR CONVEYOR 2
KGK-M9170-00 DC MOTOR ASSY. 1
KGT-M9135-00 PULLEY 1, SPLINE 2
KGT-M9193-00 NUT PLATE 4
KGY-M9140-A0 PULLEY,CONV. ASSY 4
KH2-M9105-11 PULLEY, MOTOR:P30-3GT 2
KH2-M9121-00 BEARING 2
KKE-M9135-00 PLATE, EDGE 2 8
KV7-M9140-A0 PULLEY CONV. ASSY 2
90990-41J006 COLLAR 1
91312-03010 BOLT HEX. SOCKET HEAD 8
91312-04006 BOLT HEX. SOCKET HEAD 6
91312-04008 BOLT HEX. SOCKET HEAD 2
91312-04010 BOLT HEX. SOCKET HEAD 3
91312-04055 BOLT HEX. SOCKET HEAD 4
92012-04008 BOLT, BUTTON HEAD 4
92012-04006 BOLT, BUTTON HEAD 2
91312-05010 BOLT HEX. SOCKET HEAD 2
92012-05020 BOLT, BUTTON HEAD 2
92902-04200 WASHER, PLAIN 8
92902-05200 WASHER, PLAIN 10
92902-05600 WASHER, PLAIN 4
92A08-04303 SCREW, SET 4
98702-03005 SCREW, FLAT HEAD 16
KKE-M9196-10 BRKT., CONV. MOTOR 1 L>R
KKE-M919D-11 GUIDE, HNS. 1 L>R
Main Conveyor Sub Assy C-1
KKE-M9171-00 PLATE 1, BASE 1
KKE-M9172-00 BRKT., CONVEYOR 1
KKE-M9176-00 PLATE 3, CONVEYOR 1 1250mm L=232
KKE-M9175-01 PLATE 2, CONVEYOR 1 1250mm L=232
KKE-M9177-00 STAY, CONVEYOR 1
KKE-M9178-00 PLATE 2, GUIDE 2 1250mm L=164
KKE-M9179-01 PLATE, GUIDE 1
KKE-M917A-00 GUIDE 1-1 2 1250mm L=164
KKE-M917C-00 PLATE, TENSIONER 1
KKE-M917F-00 NUT, PLATE 2
KKE-M917G-00 BELT 333-3GT-9 1
KKE-M917M-00 NUT, PLATE 2
KKE-M917R-00 STAY, SENSOR 1
KKE-M917S-00 BRKT., HNS. 1
KKE-M9A00-10 BALL SCREW 2
KG7-M9111-01 PULLEY 1 1
KG7-M9112-01 PULLEY 2 1
KGA-M9113-00 GUIDE 1, END 1
KGA-M9114-00 GUIDE 2, END 1
KH2-M9121-00 BEARING 4
KHM-M9113-01 GUIDE 1, END 1
KHM-M9114-01 GUIDE 2, END 1
KHW-M9137-00 COLLAR, BRG. 1
KHY-M9116-00 LM RAIL & BLOCK 15, 480 1
90933-03J608 BEARING 2
90990-41J071 COLLAR 2
91312-03005 BOLT HEX. SOCKET HEAD 8
91312-03008 BOLT HEX. SOCKET HEAD 6
91312-04020 BOLT HEX. SOCKET HEAD 8
91312-05020 BOLT HEX. SOCKET HEAD 1
91312-06008 BOLT HEX. SOCKET HEAD 8
91312-06012 BOLT HEX. SOCKET HEAD 8
92902-03200 WASHER, PLAIN 6
92902-05200 WASHER, PLAIN 1
97602-04306 SCREW, PAN HEAD W/W 9
$NK-2N NYLON CLIP 9
KKE-M9171-10 PLATE 1, BASE 1 L>R
KKE-M9172-10 BRKT., CONVEYOR 1 L>R
KKE-M9174-10 STAY, CONVEYOR 1 L>R
KKE-M9177-10 STAY, CONVEYOR 1 L>R
KKE-M9174-00 STAY, CONVEYOR 1
KKE-M9176-10 PLATE 3, CONVEYOR 1 L>R 1250mm L=232
KKE-M9178-50 PLATE 2, GUIDE 1 1540mm L=299
KKE-M9179-11 PLATE, GUIDE 1 L>R
KKE-M917A-50 GUIDE 1-1 2 1540mm L=299
KKE-M917R-10 STAY, SENSOR 1 L>R
92902-04200 WASHER, PLAIN 4
KKE-M9176-50 PLATE 3, CONVEYOR 1 R>L 1540mm L=367
91312-04008 BOLT HEX. SOCKET HEAD 8
91312-04006 BOLT HEX. SOCKET HEAD 13
92A08-04303 SCREW, SET 4
90990-28J076 WASHER, PLAIN 2
91312-04012 BOLT HEX. SOCKET HEAD 10
91312-05008 BOLT HEX. SOCKET HEAD 8
KKE-M917L-00 STAY, STOPPER 1 1540mm
KKE-M9175-11 PLATE 2, CONVEYOR 1 L>R 1250mm L=232
KKE-M9175-51 PLATE 2, CONVEYOR 1 R>L 1540mm L=367
KKE-M9176-60 PLATE 3, CONVEYOR 1 L>R 1540mm L=367
KKE-M9175-61 PLATE 2, CONVEYOR 1 L>R 1540mm L=367
Main Conveyor Sub Assy C-2
KKE-M917B-00 BRKT. 1, SPLINE 1
KKE-M917D-00 BRACKET, COLLAR 1
KKE-M917H-00 BELT, CONVEYOR 2 1250mm L=662
KKE-M917J-00 PULLEY 1, MOTOR 1
KKE-M917K-00 SPLINE 1 1
KKE-M917N-00 BRACKET 1 1
KKE-M917P-00 BRACKET 2 1
KKE-M9119-A0 PULLEY CONV. ASSY. 4
KKE-M9128-00 BELT 222-3GT-9 1
KG2-M9108-11 COLLAR CONVEYOR 2
KG2-M9120-01 PLATE, PULLEY CON. 7
KGK-M9170-00 DC MOTOR ASSY. 1
KGT-M9135-00 PULLEY 1, SPLINE 1
KGT-M9193-00 NUT PLATE 4
KGY-M9140-A0 PULLEY, CONV. ASSY 4
KH2-M9105-11 PULLEY, MOTOR:P30-3GT 2
KHY-M9157-00 SHAFT, MOTOR 1
90990-28J076 WASHER, PLAIN 1
90990-41J006 COLLAR 1
91312-03010 BOLT HEX. SOCKET HEAD 8
91312-04006 BOLT HEX. SOCKET HEAD 29
91312-04008 BOLT HEX. SOCKET HEAD 4
91312-04010 BOLT HEX. SOCKET HEAD 3
91312-04012 BOLT HEX. SOCKET HEAD 1
91312-04055 BOLT HEX. SOCKET HEAD 4
92902-04200 WASHER, PLAIN 6
92A08-04303 SCREW, SET 4
KKE-M917D-10 BRACKET, COLLAR 1 L>R
KKE-M917H-50 BELT, CONVEYOR 2 1540mm L=932
KKE-M917E-00 BELT, CONV. MOTOR 1
KKE-M917E-10 BELT, CONV. MOTOR 1 L>R
91312-06008 BOLT HEX. SOCKET HEAD 4
KKE-M9173-00 BRKT., CONVEYOR 1
KH2-M9121-00 BEARING 2
91312-06008 BOLT HEX. SOCKET HEAD 4
KKE-M9173-10 BRKT., CONVEYOR 1 L>R
Sensor
KKE-M652P-00 SENSOR ENT ASSY 1
KKE-M652S-01 SENSOR CV1 ASSY 1
KKE-M652T-00 SENSOR POS1 ASSY 1
KKE-M652U-00 SENSOR CVE ENT ASSY 1
KKE-M652V-00 SENSOR POS2 ASSY 1
KKE-M652W-00 SENSOR CV2 ASSY 1
KKE-M652R-00 SENSOR EXIT ASSY 1
97602-03310 SCRWE, PAN HEAD W/W 4
KHW-M9157-00 HOLDER, SENSOR 4 MFX0132-2009/12/4
KHW-M9157-00 HOLDER, SENSOR 3
91312-03005 BOLT HEX. SOCKET HEAD 2
91312-03008 BOLT HEX. SOCKET HEAD 6
98502-03004 SCREW, PAN HEAD 8
92A08-03304 SCREW, SET 8
KHM-M654C-01 SENSOR, FIBER 2 1
KHM-M654B-01 SENSOR, FIBER 1 1
Multi Camera & Light Assy
KHY-M73C0-01 C+L W50-H272-NON 1
91312-06020 BOLT HEX. SOCKET HEAD 2 M6X20
92902-06200 WASHER PLAIN 2
KJJ-M7512-01 COVER, GLASS 1
KJJ-M7513-00 DIFFUSER, COAX 1
KJJ-M7516-01 COVER, LIGHT UNIT 1
KJJ-M7518-01 FRAME, MAIN LIGHT 1
KJJ-M7522-01 PLATE, COAX. 1
KJJ-M7525-00 SPACER 4
KJJ-M7526-01 PLATE, GLASS 4
KJJ-M7542-00 AR SHEET 1
KJJ-M755S-02 M.LIGHT BOARD SET 1
KJJ-M66N2-00 HNS, M.LIGHT COAX. 1
KJJ-M66N9-01 HNS, M.LIGHT SUB CX. 1
KJJ-M66NA-01 HNS, M.LIGHT MAIN 1
KJJ-M7570-00 SPACER 12
90563-03J250 SPACER BOLT 4
90563-03J300 SPACER BOLT 2
98502-03004 SCREW PAN HEAD 4
98502-03006 SCREW PAN HEAD 6
98902-03004 SCREW BINDING HEAD 12
98902-03006 SCREW BINDING HEAD 2
98902-03010 SCREW BINDING HEAD 4
Blow Station / Dump Box
KKE-M9901-00 BASE, B. STN. 1
KHW-M9902-00 PLATE, BASE 1
KHY-M9903-00 BLOCK, BLOW ST. 1
KHW-M9904-00 BRACKET, SENSOR 2
KHW-M9905-00 PLATE, REFLECT 2
KHW-M9906-A0 VALVE ASSY. 1
KKE-M652K-00 SENSOR BLOW ST ASSY 1
KGR-M9934-01 INLINE FILTER 1
K40-M8598-10 PLUG 1 1
$NJ-32 UNIVERSAL BUSH 1
$NK-2N NYLON CLIP 2
$PF JOINT 1
$TL6-01M JOINT 1
$TL6-02 JOINT 1
90115-02J006 BOLT HEX. SOCKET HEAD 4
90990-41J066 COLLAR 4
91312-03020 BOLT HEX. SOCKET HEAD 2
91312-04008 BOLT HEX. SOCKET HEAD 4
91312-04010 BOLT HEX. SOCKET HEAD 4
91312-06016 BOLT HEX. SOCKET HEAD 2
92012-03008 BOLT, BUTTON HEAD 4
92902-06200 WASHER, PLAIN 2
97602-04308 SCREW, PAN HEAD W/W 2
KKE-M36A2-00 STAND, DUMP BOX 1
KHY-M99D1-00 DUMP BOX 1
KHY-M99D2-00 DIFFUSE PLATE 1
91312-06016 BOLT HEX. SOCKET HEAD 2
92902-06200 WASHER, PLAIN 2
KGR-M9934-F0 FILTER 1 spare
Main Cutter Assy (60-Fix)
KHY-M3T01-15 BASE PLATE 1, 720 1
KHY-M3T02-10 BASE PLATE 2, 720 1
KHY-M3T05-11 CUTTER UPPER L, 720 1
KHY-M3T05-21 CUTTER UPPER R, 720 1
KHY-M3T06-13 BASE PLATE 3, 720 1
KHY-M3T07-B2 CUTTER LOWER, 720 1
KHY-M3T08-01 BAR, L 1
KHY-M3T08-11 BAR, R 1
KHY-M3T09-11 PLATE 4, 720 1
KHY-M3T0A-01 SIDE BLOCK, L 1
KHY-M3T0A-11 SIDE BLOCK, R 1
KHY-M3T0B-11 FRONT STAY 4 2
KHY-M3T0H-30 CYL. COVER, L 1
KHY-M3T0H-40 CYL. COVER, R 1
KHY-M3T0M-00 STAY, COVER M 1
KHY-M3T0N-00 COVER M 1
KHY-M3T0P-00 CYL. COVER 1 1
KHY-M3T0U-00 SENSOR STAY 1
KHY-M3T0V-00 DOG., SENSOR 1
KHY-M3T10-01 TAPE CUTTER CYL. 1
KHY-M3T11-10 CYL. STAY 1 1
KHY-M3T12-01 CYL. BLOCK 1
KHY-M3T13-10 CYL. COLLAR 1 1
KHY-M3T14-02 CYL. COLLAR 2 1
KHY-M3T16-00 BACK STAY 2
KHY-M3T18-30 COVER L, 720 1
KHY-M3T18-40 COVER R, 720 1
KHY-M3T19-00 SIDE COVER 2
KHY-M3T22-00 SHOCK ABSORBERS 2
KHY-M3T23-00 DAMPER STAY 2
KHY-M3T24-00 DAMPER STOPPER 1
KHY-M3T26-10 CUTTER COVER, 720 1
KHY-M3T27-00 FRONT STAY 1 2
KHY-M3T28-01 FRONT STAY 2 3
KHY-M3T29-00 FRONT STAY 3 1
KHY-M3T30-00 CYL. STAY 2 1
KHY-M3T31-00 CYL. STAY 3 1
KHY-M3T32-00 CYL. STAY 4 1
KHY-M3T33-00 BOLT, HEX.S.H. 1
KKE-M652H-00 SENSOR, CUT CL ASSY 2
90K73-7L0130 LM RAIL 4
90K80-025L00 LM BLOCK, HSR25-L 4
91312-04006 BOLT HEX. SOCKET HEAD 13 M4X6
91312-04008 BOLT HEX. SOCKET HEAD 24 M4X8
91312-04010 BOLT HEX. SOCKET HEAD 2 M4X10
91312-04016 BOLT HEX. SOCKET HEAD 2 M4X16
91312-04018 BOLT HEX. SOCKET HEAD 12 M4X18
91312-05010 BOLT HEX. SOCKET HEAD 6 M5X10
91312-05020 BOLT HEX. SOCKET HEAD 8 M5X20
91312-06014 BOLT HEX. SOCKET HEAD 22 M6X14
91312-06016 BOLT HEX. SOCKET HEAD 8 M6X16
91312-06020 BOLT HEX. SOCKET HEAD 6 M6X20
91312-06022 BOLT HEX. SOCKET HEAD 10 M6X22
91312-06025 BOLT HEX. SOCKET HEAD 6 M6X25
91312-06065 BOLT HEX. SOCKET HEAD 4 M6X65
91312-08020 BOLT HEX. SOCKET HEAD 1 M8X20
92902-04600 WASHER PLAIN 2
98702-03006 SCREW FLAT HEAD 4
98902-03008 SCREW BINDING HEAD 2
98902-04008 SCREW BINDING HEAD 11
99480-04010 PIN PARALLEL: 4X10 2
91312-05012 BOLT HEX. SOCKET HEAD 3 M5X12
91312-06035 BOLT HEX. SOCKET HEAD 4 M6X40
91312-06030 BOLT HEX. SOCKET HEAD 6 M6X30
91312-04030 BOLT HEX. SOCKET HEAD 3 M4X30
$SLH6-02 JOINT 1
91312-04012 BOLT HEX. SOCKET HEAD 4
KHY-M3T13-20 SYL. COLLOR 2 1
KHY-M3T34-00 60-UPPER BLADE JIG U 1
$TL6-02 JOINT 1
Cutter Valve / Slope / Safty Cover Assy (60-Fix)
KHY-M11C1-15 DUCT 1 1
KHY-M11C3-00 BRKT, DUCT 2
KHY-M11C5-00 WASHER 6
KHY-M3T0C-00 CUTTER VALVE 1
KHY-M3T0E-11 UPPER COVER 1, 720 1
KHY-M3T0S-11 UPPER COVER 2, 720 1
KHY-M3T0X-00 STAY L 1
KHY-M3T0X-10 STAY R 1
KHY-M3T25-02 VALVE COVER 1
$KM-10 MUFFLER 2
$TL6-01M JOINT 3
90K41-000240 SEAL, DON’T TOUCH 1
90K41-000730 LABEL, ALERT 3
KHY-M1325-01 COVER 25 1
KHY-M11C6-A2 COVER 720, SUB ASSY 1
KHY-M11C2-42 DUCT 2, 720 1
KHY-M11C6-02 COVER, TAPE CUTTER 1
KJJ-M11C9-00 PLATE, NUT 1
KJJ-M5127-00 SAFETY SWITCH KEY 1
KGS-M1360-00 BOLT 2
KHU-M1117-00 PULL 1
KHY-M11CA-00 STAY, HNS. 1
KJJ-M11C8-00 BRKT, CUTTER COVER 2
KJJ-M5126-F0 SAFETY SW UNIT ASSY 1 OK MFX0093-2009/12/1
KJJ-M5126-00 SAFETY SWITCH 1
KGS-M5126-02 SCREW (M3X8) 1
KW7-M643A-00 SC LOCK 1
90990-12J001 SCREW BIN.HEAD W/W 10
90K41-000350 LABEL, ALERT 1
90K41-000730 LABEL, ALERT 2
KHY-M3T40-00 STAY HARNSS 1
91312-03020 BOLT HEX. SOCKET HEAD 2 M3X20
91312-04006 BOLT HEX. SOCKET HEAD 12 M4X6
91312-04008 BOLT HEX. SOCKET HEAD 13 M4X8
91312-04025 BOLT HEX. SOCKET HEAD 2 M4X24
91312-05008 BOLT HEX. SOCKET HEAD 10 M5X8
91312-08012 BOLT HEX. SOCKET HEAD 1 M8X12
92902-04200 WASHER PLAIN 4
92902-04600 WASHER PLAIN 15
92902-05600 WASHER PLAIN 4
98902-04006 SCREW BINDING HEAD 8
97602-04308 SCREW, PAN HEAD W/W 4
Main Cutter Assy 288 (24-Fes)
KHY-M3T01-04 BASE PLATE 1, 288 1
KHY-M3T02-00 BASE PLATE 2, 288 1
KHY-M3T05-01 CUTTER UPPER, 288 1
KHY-M3T06-03 BASE PLATE 3, 288 1
KHY-M3T07-A2 CUTTER LOWER, 288 1
KHY-M3T08-01 BAR, L 1
KHY-M3T08-11 BAR, R 1
KHY-M3T09-02 PLATE 4, 288 1
KHY-M3T10-01 TAPE CUTTER CYL. 1
KHY-M3T11-01 CYL. STAY 1
KHY-M3T12-01 CYL. BLOCK 1
KHY-M3T13-00 CYL. COLLAR 1 1
KHY-M3T14-02 CYL. COLLAR 2 1
KHY-M3T16-00 BACK STAY 1
KHY-M3T18-00 COVER L, 288 1
KHY-M3T18-10 COVER R, 288 1
KHY-M3T19-00 SIDE COVER 2
KHY-M3T22-00 SHOCK ABSORBERS 2
KHY-M3T23-00 DAMPER STAY 2
KHY-M3T24-00 DAMPER STOPPER 1
KHY-M3T26-00 CUTTER COVER, 288 1
KHY-M3T0A-01 SIDE BLOCK, L 1
KHY-M3T0A-11 SIDE BLOCK, R 1
KHY-M3T0B-03 FRONT STAY 1
KHY-M3T0H-00 CYL. COVER, L 1
KHY-M3T0H-10 CYL. COVER, R 1
KHY-M3T0L-01 CYL. COLLAR 3 1
KHY-M3T0M-00 STAY, COVER M 1
KHY-M3T0N-00 COVER M 1
KHY-M3T0P-00 CYL. COVER 1 1
KHY-M3T0U-00 SENSOR STAY 1
KHY-M3T0V-00 DOG., SENSOR 1
90K73-7L0130 LM RAIL 2
90K80-025L00 LM BLOCK, HSR25-L 2
KKE-M652H-00 SENSOR, CUT CL ASSY 4 Front Left
91312-06030 BOLT HEX. SOCKET HEAD 4 M3X4
91312-04006 BOLT HEX. SOCKET HEAD 7 M4X6
91312-04008 BOLT HEX. SOCKET HEAD 20 M4X8
91312-04010 BOLT HEX. SOCKET HEAD 2 M4X10
91312-04016 BOLT HEX. SOCKET HEAD 2 M4X16
91312-04018 BOLT HEX. SOCKET HEAD 12 M4X18
91312-05010 BOLT HEX. SOCKET HEAD 6 M5X10
99480-04010 PIN PARALLEL: 4X10 4
91312-06014 BOLT HEX. SOCKET HEAD 20 M6X14
91312-06016 BOLT HEX. SOCKET HEAD 6 M6X16
91312-06020 BOLT HEX. SOCKET HEAD 3 M6X20
91312-06022 BOLT HEX. SOCKET HEAD 4 M6X22
91312-06025 BOLT HEX. SOCKET HEAD 3 M6X25
91312-08020 BOLT HEX. SOCKET HEAD 4 M8X20
98902-04008 SCREW BINDING HEAD 6
92902-04600 WASHER PLAIN 2
92B12-10035 SCREW, H.S.COUN. 1
98702-03006 SCREW FLAT HEAD 4
98902-03008 SCREW BINDING HEAD 2
$TL4-02 JOINT 2
91312-05018 BOLT HEX. SOCKET HEAD 4
Cutter Valve / Slope / Safty Cover Assy (24-Fes)
KHY-M3T0C-00 CUTTER VALVE 1
$TL6-01M JOINT 3
$KM-10 MUFFLER 2
KHY-M11C1-04 DUCT 1 1
KHY-M11C3-00 BRKT., DUCT 2
KHY-M11C4-00 BRKT., DUCT 2
KHY-M11C5-00 WASHER 5
KHY-M3T0E-01 UPPER COVER 1, 288 1
KHY-M3T0S-01 UPPER COVER 2, 288 1
KHY-M3T0R-00 STAY L 1
KHY-M3T0R-10 STAY R 1
90K41-000730 LABEL, ALERT 3
90K41-000240 SEAL, DON’T TOUCH 1
KHY-M1325-01 COVER 25 1
KHY-M11C6-B2 COVER 2880, SUB ASSY 1
KHY-M11C2-52 DUCT 2, 288 2
KHY-M11C6-02 COVER, TAPE CUTTER 1
KJJ-M11C9-00 PLATE, NUT 1
KJJ-M5127-00 SAFETY SWITCH KEY 1
KGS-M1360-00 BOLT 2
KHU-M1117-00 PULL 1
KJJ-M11C8-00 BRKT., CUTTER COVER 2
KJJ-M5126-F0 SAFETY SW UNIT ASSY 1 OK MFX0093-2009/12/1
KJJ-M5126-00 SAFETY SWITCH 1
KGS-M5126-02 SCREW (M3X8) 1
KW7-M643A-00 SC LOCK 1
90990-12J001 SCREW BIN. HEAD W/W 10
90K41-000350 LABEL, ALERT 1
90K41-000730 LABEL, ALERT 2
91312-03020 BOLT HEX. SOCKET HEAD 2 M3X20
91312-04006 BOLT HEX. SOCKET HEAD 12 M4X6
91312-04008 BOLT HEX. SOCKET HEAD 13 M4X8
91312-04025 BOLT HEX. SOCKET HEAD 2 M4X24
91312-05008 BOLT HEX. SOCKET HEAD 10 M5X8
92902-04200 WASHER PLAIN 4
92902-04600 WASHER PLAIN 13
92902-05600 WASHER PLAIN 4
98902-04006 SCREW BINDING HEAD 4
97602-04308 SCREW, PAN HEAD W/W 2
$NK-3N NYLON CLIP 2
KJJ-M3T25-10 VALEVE COVER 2 1
KJJ-M11CA-00 STAY, HNS. 1
KHY-M3T40-00 STAY, HARNESS 1
Main Cutter Assy (24-Fix)
KHY-M3T01-04 BASE PLATE 1, 288 1
KHY-M3T02-00 BASE PLATE 2, 288 1
KHY-M3T05-01 CUTTER UPPER, 288 1
KHY-M3T06-03 BASE PLATE 3, 288 1
KHY-M3T07-A2 CUTTER LOWER, 288 1
KHY-M3T08-01 BAR, L 1
KHY-M3T08-11 BAR, R 1
KHY-M3T09-02 PLATE 4, 288 1
KHY-M3T10-01 TAPE CUTTER CYL. 1
KHY-M3T11-01 CYL. STAY 1
KHY-M3T12-01 CYL. BLOCK 1
KHY-M3T13-00 CYL. COLLAR 1 1
KHY-M3T14-02 CYL. COLLAR 2 1
KHY-M3T16-00 BACK STAY 1
KHY-M3T18-00 COVER L, 288 1
KHY-M3T18-10 COVER R, 288 1
KHY-M3T19-00 SIDE COVER 2
KHY-M3T22-00 SHOCK ABSORBERS 2
KHY-M3T23-00 DAMPER STAY 2
KHY-M3T24-00 DAMPER STOPPER 1
KHY-M3T26-00 CUTTER COVER, 288 1
KHY-M3T0A-01 SIDE BLOCK, L 1
KHY-M3T0A-11 SIDE BLOCK, R 1
KHY-M3T0B-03 FRONT STAY 1
KHY-M3T0H-00 CYL. COVER, L 1
KHY-M3T0H-10 CYL. COVER, R 1
KHY-M3T0L-01 CYL. COLLAR 3 1
KHY-M3T0M-00 STAY, COVER M 1
KHY-M3T0N-00 COVER M 1
KHY-M3T0P-00 CYL. COVER 1 1
KHY-M3T0U-00 SENSOR STAY 1
KHY-M3T0V-00 DOG., SENSOR 1
90K73-7L0130 LM RAIL 2
90K80-025L00 LM BLOCK, HSR25-L 2
KKE-M652H-00 SENSOR, CUT CL ASSY 4
91312-06030 BOLT HEX. SOCKET HEAD 4 M3X4
91312-04006 BOLT HEX. SOCKET HEAD 7 M4X6
91312-04008 BOLT HEX. SOCKET HEAD 20 M4X8
91312-04010 BOLT HEX. SOCKET HEAD 2 M4X10
91312-04016 BOLT HEX. SOCKET HEAD 2 M4X16
91312-04018 BOLT HEX. SOCKET HEAD 12 M4X18
91312-05010 BOLT HEX. SOCKET HEAD 6 M5X10
99480-04010 PIN PARALLEL: 4X10 4
91312-06014 BOLT HEX. SOCKET HEAD 20 M6X14
91312-06016 BOLT HEX. SOCKET HEAD 6 M6X16
91312-06020 BOLT HEX. SOCKET HEAD 3 M6X20
91312-06022 BOLT HEX. SOCKET HEAD 4 M6X22
91312-06025 BOLT HEX. SOCKET HEAD 3 M6X25
91312-08020 BOLT HEX. SOCKET HEAD 4 M8X20
98902-04008 SCREW BINDING HEAD 6
92902-04600 WASHER PLAIN 2
92B12-10035 SCREW, H.S.COUN. 1
98702-03006 SCREW FLAT HEAD 4
98902-03008 SCREW BINDING HEAD 2
$TL4-02 JOINT 2
91312-05018 BOLT HEX. SOCKET HEAD 4
Cutter Valve / Slope / Safty Cover Assy (24-Fix)
KHY-M3T0C-00 CUTTER VALVE 1
$TL6-01M JOINT 3
$KM-10 MUFFLER 2
KHY-M11C1-04 DUCT 1 1
KHY-M11C3-00 BRKT., DUCT 2
KHY-M11C4-00 BRKT., DUCT 2
KHY-M11C5-00 WASHER 5
KHY-M3T0E-01 UPPER COVER 1, 288 1
KHY-M3T0S-01 UPPER COVER 2, 288 1
KHY-M3T0R-00 STAY L 1
KHY-M3T0R-10 STAY R 1
90K41-000730 LABEL, ALERT 3
90K41-000240 SEAL, DON’T TOUCH 1
KHY-M1325-01 COVER 25 1
KHY-M11C6-A2 COVER 720, SUB ASSY 1
KHY-M11C2-42 DUCT 2 1
KHY-M11C6-02 COVER, TAPE CUTTER 1
KJJ-M11C9-00 PLATE, NUT 1
KJJ-M5127-00 SAFETY SWITCH KEY 1
KGS-M1360-00 BOLT 2
KHU-M1117-00 PULL 1
KJJ-M11C8-00 BRKT., CUTTER COVER 2
KJJ-M5126-F0 SAFETY SW UNIT ASSY 1 OK MFX0093-2009/12/1
KJJ-M5126-00 SAFETY SWITCH 1
KGS-M5126-02 SCREW (M3X8) 1
KW7-M643A-00 SC LOCK 1
90990-12J001 SCREW BIN. HEAD W/W 10
90K41-000350 LABEL, ALERT 1
90K41-000730 LABEL, ALERT 2
91312-03020 BOLT HEX. SOCKET HEAD 2 M3X20
91312-04006 BOLT HEX. SOCKET HEAD 12 M4X6
91312-04008 BOLT HEX. SOCKET HEAD 13 M4X8
91312-04025 BOLT HEX. SOCKET HEAD 2 M4X24
91312-05008 BOLT HEX. SOCKET HEAD 10 M5X8
92902-04200 WASHER PLAIN 4
92902-04600 WASHER PLAIN 13
92902-05600 WASHER PLAIN 4
98902-04006 SCREW BINDING HEAD 4
97602-04308 SCREW, PAN HEAD W/W 2
$NK-3N NYLON CLIP 2
KJJ-M3T25-11 VALEVE COVER 2 1
KJJ-M11CA-00 STAY, HNS. 1
KHY-M3T40-00 STAY, HARNESS 1
Non Tape Cutter
KHY-M3T0E-30 UPPER COVER 1, 720 1
KHY-M3T0S-11 UPPER COVER 2, 720 1
KHY-M3T0X-00 STAY L 1
KHY-M3T0X-10 STAY R 1
KHY-M11C1-15 DUCT 1 1
KHY-M11C2-30 DUCT 2 1
KHY-M11C3-00 BRKT., DUCT 2
KHY-M11C5-00 WASHER 6
91312-04006 BOLT HEX. SOCKET HEAD 8 M4X6
91312-04008 BOLT HEX. SOCKET HEAD 6 M4X8
91312-05008 BOLT HEX. SOCKET HEAD 8 M5X8
91312-06010 BOLT HEX. SOCKET HEAD 4 M6X10
92902-04600 WASHER PLAIN 12
98902-04006 SCREW BINDING HEAD 3
KHY-M3T0E-21 UPPER COVER 1, 284 1
KHY-M3T0S-01 UPPER COVER 2, 288 1
KHY-M3T0R-00 STAY L 1
KHY-M3T0R-10 STAY R 1
KHY-M11C1-04 DUCT 1 1
KHY-M11C2-20 DUCT 2 1
KHY-M11C3-00 BRKT., DUCT 1
KHY-M11C4-00 BRKT., DUCT 1
KHY-M11C5-00 WASHER 5
91312-04006 BOLT HEX. SOCKET HEAD 8 M4X6
91312-04008 BOLT HEX. SOCKET HEAD 6 M4X8
91312-05008 BOLT HEX. SOCKET HEAD 5 M5X8
91312-06010 BOLT HEX. SOCKET HEAD 3 M6X10
92902-04200 WASHER PLAIN 2
92902-04600 WASHER PLAIN 10
92902-06600 WASHER PLAIN 2
98902-04006 SCREW BINDING HEAD 3
Set Up ST on MC
KHJ-MD101-00 FEEDER PLATE 1
KHJ-MD102-00 SIDE PLATE, L 1
KHJ-MD103-00 SIDE PLATE, R 1
KHJ-MD104-00 CLAMP PLATE 1. 1
KHJ-MD105-00 FEEDER STOPPER 1
KHJ-MD106-00 CONNECTOR PLATE 1
KHJ-MD107-00 UNDER COVER 1
KHJ-MD108-00 BACK COVER 1
KHJ-MD109-00 SWITCH COVER 1
KHJ-MD110-00 LABEL, PITCH 1
KHJ-MD111-01 RAIL GUIDE 1
KHJ-MD112-00 GROMMET 1
KHY-M379K-00 LABEL, LED POSI. 1
KHJ-M4484-02 FDR. ST. BOARD ASSY 1
KHJ-M4486-00 PITCH LED BOARD ASSY 1
KHJ-M663B-10 HNS, PITCH LED 1
KHJ-M663C-10 HNS, PITCH UP 1
KHJ-M663D-10 HNS, PITCH DOWN 1
KHJ-M663E-10 HNS, PITCH SET 1
KHY-M66TE-00 HNS, F. CTRL-FDR. 1
KHY-M66RK-00 HNS, FDR. ST. 1
KHY-M372M-00 SCREW, STAD 2
KHJ-MD113-00 PROTECT, CONNECTOR 1
KHJ-MD114-00 PIN, HUNG L 1
KHJ-MD115-00 PIN, HUNG R 1
KHJ-MD120-00 REELHOLDER EQUIP. 1
KHJ-MD121-01 SIDE PLATE, L 1
KHJ-MD122-01 SIDE PLATE, R 1
KHJ-MD123-00 SHAFT 3
KHJ-MD12A-00 PARTITION ASSY 1
KHJ-MD210-00 FOOT 6
91312-03006 BOLT HEX. SOCKET HEAD 2
91312-03008 BOLT HEX. SOCKET HEAD 6
91312-06010 BOLT HEX. SOCKET HEAD 8
98902-03004 SCREW BINDING HEAD 2
98902-03006 SCREW BINDING HEAD 10
98902-03008 SCREW BINDING HEAD 1
98902-04006 SCREW BINDING HEAD 5
98902-06010 SCREW BINDING HEAD 4
90990-12J001 SCREW BIN.HEAD W/W 16
98702-03005 SCREW FLAT HEAD 4
90172-00J060 WASHER, EXTL.TOOTHED 4
92902-06200 WASHER PLAIN (N) 12
FDR Power ST
KHJ-MD201-00 FEEDER PLATE 1
KHJ-MD202-00 SIDE PLATE, L 1
KHJ-MD203-00 SIDE PLATE, R 1
KHJ-MD204-00 CLAMP PLATE 1
KHJ-MD205-00 FEEDER STOPPER 1
KHJ-MD206-00 CONNECTOR PLATE 1
KHJ-MD207-00 UNDER COVER 1
KHJ-MD208-00 BACK COVER 1
KHJ-MD209-00 BASE PLATE 1
KHJ-MD210-00 FOOT 4
KJJ-M371R-000 RAIL GUIDE 16P 1
KHJ-MD212-00 BKT. SWITCH 1
KHJ-MD213-00 REEL HOLDER, FIX. 1
KHJ-MD214-00 REEL HOLDER, MOVE 1
KHJ-MD110-00 LABEL, PITCH 1
KHJ-M4484-02 FDR. ST. BOARD ASSY 1
KHJ-M4486-00 PITCH LED BOARD ASSY 1
KJ3-M6511-00 CIRCUIT PROTECTOR, 1 1
KHJ-M537A-00 NOISE FILTER 1
KHJ-M6561-10 POWER SUPPLY 1 1
KHJ-M661B-01 HNS, AC IN 2 1
KHJ-M662A-00 HNS, CP DC24V 1
KHJ-M662B-00 HNS, LAMP 1
KHJ-M662C-000 HNS, BRD.PWR 1
KHJ-M663C-00 HNS, PITCH UP 1
KHJ-M663D-00 HNS, PITCH DOWN 1
KHJ-M663E-00 HNS, PITCH SET 1
KHY-M66TE-00 HNS, F. CTRL-FDR. 1
KJ3-M662A-00 HNS, AC IN 1 1 Abroad parts
KJ3-M661A-00 HNS, AC IN 1 1 Domestis parts
KHJ-MD215-001 LABEL, SERIAL 1
KHA-M5184-11 SEAL, LABEL 1
KHY-M6417-00 SEAL, CE 1
KHY-M372M-00 SCREW, STAD 2
90563-03J100 SPACER BOLT 4
92902-03200 WASHER PLAIN 4
98902-03004 SCREW BINDING HEAD 4
98902-03005 SCREW BINDING HEAD 28
98902-04006 SCREW BINDING HEAD 10
98702-03006 SCREW FLAT HEAD 8
91312-03006 BOLT HEX. SOCKET HEAD 3 M3X8
91312-03008 BOLT HEX. SOCKET HEAD 4 M3X7
90990-11J003 SCREW, PAN HEAD W/W 16
$NK-3N NYLON CLIP 12
FDR Stand Type144
KHJ-MK001-10 MAIN FRAME 1
KHJ-MK002-00 FEEDER-48 PLATE (12) 3
KHJ-MK003-00 BRACKET, 1 3
KHJ-MK004-00 BRACKET, 2 3
KHY-M371R-00 RAIL GUIDE 12P 12
KM0-M3741-00 CASTER 63 4
92902-04200 WASHER, PLAIN 30
98702-03006 SCREW, FLAT HEAD 120
91312-04008 BOLT HEX. SOCKET HEAD 31
91312-06008 BOLT HEX. SOCKET HEAD 24
KHY-M373C-10 CHAIN 1
KHJ-MK007-00 STOPPER 2
Control Box
KJJ-M411B-00 BRACKET 2 2
KJJ-M411A-00 PLATE 2
KJJ-M4119-00 BRACKET 1 FILTER 1
KJJ-M4120-00 BRACKET 2 FILTER 1
KJJ-M4510-02 MOTHER BOARD ASSY 1
KKE-M5840-00 SERVO BOARD ASSY 2
KHN-M5840-50 SERVO BOARD ASSY 1
KHN-M5840-A0 SERVO BOARD ASSY 1
KHL-M4209-01 SYSTEM UNIT ASSY 1 S.T.D
KHL-M4209-21 SYSTEM UNIT ASSY 1 IT O/P
KHN-M4530-35 REMOTE IF BOARD ASSY 1
KHL-M441H-43 VISION BOARD ASSY 1
KHN-M4530-55 REMOTE IF BOARD ASSY 1
KJJ-M5880-00 DRIVER POWER ASSY 1
KJJ-M4454-01 RAS BOARD ASSY 1
KJJ-M4250-00 BACKPLANE BOARD ASSY 1
KHL-M4255-00 FLASH DISK 1
KGS-M5303-00 SW POWER DC5 1
KGS-M5303-10 SW POWER DC12 1
KJJ-M4186-00 FAN MOTOR ASSY 1
KJJ-M4186-10 FAN MOTOR ASSY 1
KJJ-M4186-20 FAN MOTOR ASSY 1
KKE-M4186-00 FAN MOTOR ASSY 1
KJ3-M4187-00 FAN GUARD 1
KJJ-M53A9-10 FILTER 1
KJJ-M53A9-20 FILTER 2
KJJ-M53E9-10 TAPE 1
KJJ-M53E9-20 TAPE 2
91312-04006 BOLT HEX. SOCKET HEAD 8 M4X6
90166-12JA10 SCREW, PAN HEAD 8
97602-04308 SCREW, PAN HEAD W/W 71
KKE-M4141-00 DUMMY PANEL SYS 1
Exterior, etc 1
KGT-M5106-02 15 NORMAL LCD” 2
KKE-M1390-00 LCD STAY ASSY. 2
KGB-M3992-00 SWITCH SELECT 4
KW3-M5150-50 KEYBOARD J 1
KW3-M5150-60 KEYBOARD E 1
KW3-M5169-04 MOUSE 1
KHY-M13B1-B0 BRKT. KEYBOARD ASSY. 1
KGA-M13B5-00 MOUSE POCKET ASSY 1
KKE-M4899-00 LIGHT 1 (L=404) 1
KKE-M4899-10 LIGHT 1 (L=654) 1
KKE-M4899-20 LIGHT 1 (L=654) 1
KKE-M4899-30 LIGHT 1 (L=654) 1
KKE-M4899-40 LIGHT 1 (L=854) 1
KKE-M4899-50 LIGHT 1 (L=854) 1
KKE-M4899-60 LIGHT 1 (L=404) 1
KKE-M4899-70 LIGHT 1 (L=654) 1
KKE-M4899-80 LIGHT 1 (L=654) 1
KKE-M4899-90 LIGHT 1 (L=654) 1
KKE-M4899-A0 LIGHT 1 (L=854) 1
KKE-M4899-B0 LIGHT 1 (L=854) 1
KKE-M6554-00 MAIN SWITCH 1
KGK-M6680-20 HNS, USB-MEMORY 2M AS 1
KKE-M6185-20 FAN MOTOR ASSY 2
KKE-M6185-60 FAN MOTOR ASSY 1
KKE-M6185-00 FAN MOTOR ASSY 2
KKE-M6185-70 FAN MOTOR ASSY 1
KGS-M4896-01 LIGHT, ERR ASSY 1 for STD
KHG-M4896-01 LIGHT, ERR ASSY 1 for CE
KGK-M5138-00 SWITCH. EMG ASSY 2
KHY-M8596-00 PRESSURE GAUGE 2
KGY-M4268-00 USB MEMORY 1 YAMAHA
KGY-M4268-10 USB MEMORY 1 ASSEMBLEON
KKE-M6185-10 FAN MOTOR ASSY 1
KJJ-M4554-00 TERMINAL BOARD ASSY 1
KKE-M6185-50 FAN MOTOR ASSY 1 OK MFX0027-2009/12/8
KKE-M6185-50 FAN MOTOR ASSY 2
Delete MFX0027-2009/12/8
KKE-M6185-30 FAN MOTOR ASSY 2
KKE-M669V-00 HNS, SWITCH ACTIVE 1
KKE-M669V-10 HNS, SWITCH READY 1
KKE-M669V-20 HNS, SWITCH START 1
KKE-M669V-30 HNS, SWITCH STOP 1 for STD
KKE-M669V-40 HNS, SWITCH ERR.CLR. 1 for STD
KKE-M669V-50 HNS, SWITCH RESET 1
KKE-M669V-60 HNS, SWITCH STOP 1 for CE
KKE-M669V-70 HNS, SWITCH ERR. CLR. 1 for CE
Exterior, etc 2
KJJ-M5318-30 POWER TRANSFORMER 1
KKE-M5328-00 POWER TRANSFORMER 1
KHG-M6513-01 CIRCUIT PROTECTOR, 1P 1
KV5-M1130-00 CATCH MG. 2
KW7-M5127-00 SAFETY SWITCH KEY 2
KKE-M6561-00 POWER SUPPLY 1 1
KJJ-M4554-00 TERMINAL BOARD ASSY 1
KKE-M6513-20 CIRCUIT PROTECTOR, 3P 1
KHN-M6513-01 CIRCUIT PROTECTOR, 1P 1
KHN-M6513-11 CIRCUIT PROTECTOR, 1P 1
KGS-M6511-00 MAIN BREAKER, 1 1
KHN-M643A-00 TERMINAL, POWER 4
KHU-M6511-00 MAIN BREAKER, 1 1
KKE-M6513-00 CIRCUIT PROTECTOR, 1P 1
KHN-M6513-21 CIRCUIT PROTECTOR, 1P 1
KKE-M6513-30 CIRCUIT PROTECTOR, 1P 2
KW7-M5126-H0 SAFETY SW UNIT ASSY 2 FIX60/FIX24 Type OK MFX0093-2009/12/1
KW7-M5126-G0 SAFETY SW UNIT ASSY 2 FES24 Type OK MFX0093-2009/12/1
KW7-M5126-00 SAFETY SWITCH 2
KGA-M6513-11 CIRCUIT PROTECTOR, 2P 1
KKE-M6513-50 CIRCUIT PROTECTOR, 2P 1
KKE-M6561-10 POWER SUPPLY 1 1
KHN-M6561-00 POWER SUPPLY 1 1
98902-03005 SCREW BINDING HEAD 8
0865752936
